Specifications
1.Fiber Optic SC Connector Pigtail2.Polishing:PC/UPC/APC
3.PVC,LSZH.OM3,OFNR
4.RoHS compliant
5.Good quality&Fast deliv
SC SM 0.9MM Pigtail
Features
* Low insertion loss, high return loss
* Excellent mechanical endurance
* High reliability and stability
* Good repeatability and exchangeability
Application
* FTTX + LAN
* Optical fiber CATV
* Optical communication system
* Telecommunication
Ordering Information
* Ceonnector type:FC,SC,LC,LC,ST,MTRJ,MU,E2000,MPO,DIN,D4,SMA
* Ferrule End-face:PC,SPC,UPC,APC
* Core Type:Single-mode(SM:9/125um),Multi-mode(MM:50/125um or 62.5/125um)
* Cable Quantity:Simplex,Duplex
* Cable Diameter:Φ3.0mm,Φ2.0mm,Φ0.9mm
* Cable Length:1,2,3 meter or customized
* Cable Type:PVC,LSZH,OM3,OFNR,OFNP,Plenum,Armoured...
* Color:Yellow,Orange,Green,Gray,Red,Purple...
Specification
Parameter |
type |
PC |
SPC |
UPC |
APC |
Insertion Loss |
SM |
≤0.25dB |
≤0.20dB |
≤0.20dB |
≤0.15dB |
MM |
≤0.30dB |
≤0.20dB |
≤0.20dB |
≤0.30dB |
|
Return Loss |
SM |
≥45dB |
≥50dB |
≥55dB |
≥65dB |
MM |
≥35dB |
≥35dB |
≥35dB |
≥35dB |
|
Mating Durability(500 timer) |
Additional Loss≤0.1dB, Return Loss Variability<5dB |
||||
Temperature Stability(-40°C~75°C) |
Additional Loss≤0.2dB, Return Loss Variability<5dB |
||||
Operating Temperature |
-40°C~+75°C |
||||
