300w Small Vertical Axis Wind Generator

Name: 300w Small Vertical Axis Wind Generator
Brand: NaiEr
SKU: 113305335

US$ 350 - 600 MOQ: 1 Set

Key Specifications

Place of Origin:

China

Brand Name:

NaiEr

Model Number:

s-300

Jiangsu Naier Wind Power Technology Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name NaiEr

Model Number s-300

Type Wind Power Generator

small vertical axis wind generator Features:

VAWTs are not affected by the direction of the wind, which is useful in areas where the wind changes direction frequently and quickly. Unlike traditional horizontal axis wind turbines, a yaw mechanism is not needed to turn the wind turbine towards the wind.
Because of this, VAWTs outperform horizontal axis turbines in areas where a tall tower isn't feasible
VAWTs are better able to harvest turbulent air flow found around buildings and other structures
VAWTs are ideal for both rural and urban applications, including roof top installations. Depending on the shape of the roof, the wind flow over the roof can be concentrated, leading to an increased energy output
Simple to install and maintain
Quiet operation
Pleasant appearance

small vertical axis wind generator Technical Data:

Rated power	300w
Rated voltage	12/24v
Start-up wind speed	2m/s
Rated wind speed	11.5m/s
Survival wind speed	50m/s
Top net weight	35kg
Wheel diameter	0.6m
wheel height	1.2m
Number of blades	2
Blades material	reinforced glass fiber
Generator	three phase ac permanent magnet generator
Magnet	NdFeB
Generator case	aluminum alloy
Control system	electronic magnet
Speed regulation	auto windward
Working temperature	'-40-80℃
