BASIC SPECIFICATIONS TRACTOR TRUCK DRIVING TYPE 4×2 | ||
Model |
M2640T |
|
Type |
N3 |
|
Engine |
Engine model: Weichai WP12.400N |
|
Type: Diesel, 4-stroke, direct injection engine | ||
6-cylinder in-line with water cooling, turbocharged & intercooled | ||
Turbocharger: HOLSAT Turbocharger | ||
Injection pump: BOSCH Common Rail system | ||
Injector: BOSC | ||
Maximum output according to DIN: 294Kw at 1900 rpm, 400hp | ||
Maximum torque: 1920 N.m at 1000~1400 rpm | ||
Bore: 126 mm | ||
Stroke: 155 mm | ||
Displacement: 11.596 L | ||
Compression ratio: 17:1 | ||
Min. fuel consumption: ≤198 g/kwh | ||
Displacement criterion: EURO 3 | ||
Idle speed: 600±50 r/min | ||
Dimensions: 1611.4*820*1094.3mm(with fan) | ||
Clutch |
Model: φ430, diaphragm spring clutch, Single-plate dry clutch, France VOLEO |
|
Type: Hydraulic operating, compressed air assisted | ||
Transmission |
Model: FAST 12JS200TA, with half gear, with overran gear |
|
Operating type: Hydraulic with air assistant | ||
Type: With constant-mesh-gear synchronizer Maximum torque:2000NM | ||
Constant-mesh: 12 forward & 2 reverse, with half gear, with Overran | ||
|
Ratio: 12.10; 9.41; 7.31; 5.71; 4.46; 3.48; 2.71; 2.11; 1.64; 1.28; 1.00; 0.78 11.56(r); 2.59(r) | ||
Dry weight: 350 kg | ||
Wheels |
Tyres 12.00R20 |
|
Wheel hub: 8.5-20 | ||
Tyres Number: 6+1 | ||
Front axle |
Model: Styre 6.5T |
|
Type: Rigid stub axle with T type | ||
Rear axles |
Model: Strye 13ton |
|
Type: Central and hub reduction | ||
Ratio: 4.38 | ||
Suspension |
Type: Non-independent suspension |
|
Front suspension: Parabolic leaf springs, with stabilizer and Telescopic cylinder shock absorber | ||
Rear suspension: Air balloon suspension of GoodYear, with stablizer and Telescopic cylinder shock absorber | ||
Chassis |
Classification: thickness 8+6mm, Front 940mm, Rear 850mm, 300+90mm |
|
Steering system |
Model: ZF8098, (Germany ZF , made in China) |
|
Type: Steering with total power assisted | ||
Ratio: 23:1 | ||
Max. Pressure of steering oil pump (kPa): 17000 | ||
Steering oil: HVN32, 3.5L | ||
Braking system |
Service brake: Dual circuit compressed air brake, WABCO ABS/ASR |
|
Parking brake: Spring energy compressed air brake | ||
Auxiliary brake: Engine exhaust brake, with Germany MAN EVB | ||
Driver’s cab |
Model: ZXPW21 |
|
Type: All-steel forward control, tiltable to front, rear airbag suspension, CD and radio-receiver recorder, air conditioning, desert air filter, central control door-lock, one Sleeper beds, air suspension seats, flat roof, DVD | ||
Seats: 2 | ||
Passengers: 3 | ||
Cab size (mm): 2030*2490*2623 | ||
Electrics |
Operating voltage: 24V, negative grounded |
|
Starter: 24V, 6.2KW | ||
Alternator: 2.2KW | ||
Batteries: 24V, 165Ah | ||
Instrument panel |
Active check control with indicators, with this instrument the daily manual checks on the vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure and battery charging |
|
Dimensions in mm |
Wheelbase |
3600 mm |
Front tread |
2027 mm |
|
Rear tread |
1865 mm |
|
Front overhang |
1495mm |
|
Rear overhang |
1010 mm |
|
Approach angle |
(27°) |
|
Departure angle |
(46.5°) |
|
Overall length |
6105 mm |
|
Overall width |
2490 mm |
|
Overall Height |
3130 mm |
|
Weight in kg |
Maximum towing capacity |
35000kg |
Dead weight |
6945 kg |
|
Fifth wheel loading |
12055kg |
|
Gross vehicle weight |
19000kg |
|
GCW |
42000Kg |
|
Front axle loading capacity |
6500 kg |
|
Rear axles loading capacity |
13000 kg |
|
Performance |
Maximum driving speed (km/h) |
108 |
Fuel tank capacity (L) |
430 |
|
Maximum grade ability (%) |
38 |
|
Minimum ground clearance (mm) |
320 |
|
Fuel consumption (L/100km) |
38 |
|
Min. turning diameter (m) |
14 |
|
