Home > Instruments & Meters > Test Instrument > Test Machine > ST9931 - ELECTRICAL SAFETY TESTER

ST9931 - ELECTRICAL SAFETY TESTER

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

MCP

Model Number:

ST9931

Contact Supplier Request Quote Chat Now

Shanghai MCP Corp.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name MCP

Model Number ST9931

Specifications

.AC/DC withstanding voltage test,insulation resistance test,ground resistance test & Leakage
.Programmable test
.SAFETY TESTER

ST9931 - ELECTRICAL SAFETY TESTER

Feature
.AC/DC withstanding voltage test,insulation resistance test,ground resistance test & Leakage
.Programmable test
.Fast sampling rate,high efficiency
.Large 320×240 graphic LCD
.50 memory units with 8steps in each
.True RMS leakage current measurement
.Standard PLC interface
.Option RS-232,RS-485,USB,GPIB

Specification
Withstanding Voltage Test
.Voltage Range:0.050∼5.000KVAC 0.050∼6.000KVDC
.Accuracy:±(2%+5digits)
.Test current:0.001∼40mAAC 0.001∼20mADC
.Accuracy:±(2%+2digits)
.Test time:0∼999.9S
.Test frequency:50/60Hz
.Arc detection:0∼40mAAC 0∼20mADC
Insulation Resistance Test(ST9930/ST9932)
.Resistance Range:1MΩ∼9.999GΩ
.Test Voltage: 100∼1000VC
.Accuracy:±(2%+5V)
.Test time:0∼999.9S
.Leakage current & Ground resistance test

Model	Leakage Current			Ground resistance
Model	Voltage Range	Test Current	Transformer	Test Current	Test Range	Accuracy	Test time
ST9930	30∼300V	0∼20mA	300VA
ST9931	30∼300V	0∼20mA	300VA	3~30A	0~510mΩ	±(2%+2mΩ)	0~999.9S
ST9932				3~30A	0~510mΩ	±(2%+2mΩ)	0~999.9S
