MV2172 - MILLI VOLTAGE METER

Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

MCP

Model Number:

MV2172

Shanghai MCP Corp.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name MCP

Model Number MV2172

Display Type Analog Only

Measuring Range 30 μV~100V

Accuracy Class ±3%

Operating Temperature 0 ~ + 40℃

Dimensions 125*185*270mm

Specifications

30uV full scale sensitivity
Measures frequency from 10Hz to 2MHz
Measure range from -70dB to +40dB in 12 steps
Voltage meter

MV2172 - MILLI VOLTAGE METER

Features

.30μV full scale sensitivity
.Measures frequency from 10Hz to 2MHz
.Measure range from -70dB to +40dB in 12 steps
.Dual channel

MV2171/MV2172
Input voltage range	30μV~100V of full scale 12 steps
Input decibel range	-70dB ~ +40dB 12 steps (0dBV=1V, 0dBm=1mW 600Ω)
Accuracy	±3% (reference 400Hz)
Frequency response	20Hz~100kHz ±3%, 10Hz~2MHz ±8% (reference 400Hz)
Input impendence	≥1MΩ, ≤50pF (300μV~300mV of 7 steps)
	≥8MΩ, ≤20pF (1V~100V of 5 steps)
Operation error	±5% (20Hz~100kHz ), ±10% (10Hz~2MHz ) (Temperature: 0~+40, Humidity: ≤80%)
Noise	≤3% of full scale
Surveillant magnifier	Output voltage: 1V±5% Frequency response: 10Hz~2MHz±3dB (reference 400Hz)
Overload voltage	100V for AC peak (300μV~1V of 8 steps) 300V for AC peak (3V~100V of 4 steps)
Power supply	110 ~ 127VAC±10%/220 ~ 240VAC±10%, 50Hz±2Hz/60Hz±2Hz
Weight	2kg
Dimensions (WxHxD)	125mm x 185mm x 270mm
Accessories	one operation manual, one power cord, one fuse, one detector
