2015 New Submersible Solar Water Pump
SUBMERSIBLE DC SOLAR PUMP (Screw Type Pump)
| Model | Screw / Impeller | Voltage (V) | Power (W) | Max. Flow (M³/H) | Max. Head (m) | Outlet (Inch) | Diameter* Length (mm) | Weight (Kg) |
| 3SPS0.72/20-D12/80 | Stainless steel Rotor | 12--26 | 45-150 | 0.72 | 20 | G0.75" | 76*400 | 6.5 |
| 3SPS0.76/28-D12/120 | 12--26 | 120 | 0.76 | 28 | G0.75" | 6.7 | ||
| 3SPS0.86/38-D12/150 | 12--26 | 150 | 0.86 | 38 | G0.75" | 6.8 | ||
| 3SPS1.0/30-D24/80 | 16-36 | 45-150 | 1 | 30 | G0.75" | 7 | ||
| 3SPS1.3/50-D24/140 | 16-36 | 80-200 | 1.3 | 50 | G0.75" | 7.2 | ||
| 3SPS1.8/80-D24/210 | 16-36 | 100-270 | 1.8 | 80 | G0.75" | 7.5 | ||
| 3SPS1.8/100-D36/270 | 24-48 | 140-350 | 1.8 | 100 | G0.75" | 8 | ||
| 3SPS1.8/120-D36/500 | 24-48 | 320-800 | 1.8 | 120 | G0.75" | 9 | ||
| 3SPS2.3/140-D48/750 | 36-72 | 480-950 | 2.3 | 140 | G0.75" | 9 | ||
| 3SPS2.3/160-D72/1000 | 48-96 | 600-1200 | 2.3 | 160 | G0.75" | 9.5 | ||
| 3SPS2.3/180-D72/1300 | 72-144 | 800-1500 | 2.3 | 180 | G0.75" | 9.5 | ||
| 4SPS3/60-D36/500 | 24-48 | 300-700 | 3 | 60 | G1" | 100*480 | 10 | |
| 4SPS3.6/80-D48/750 | 36-72 | 450-1000 | 3.6 | 80 | G1" | 10.5 | ||
| 4SPS4/100-D72/1000 | 48-96 | 600-1300 | 4 | 100 | G1" | 100*550 | 13.5 | |
| 4SPS4.2/120-D72/1300 | 72-144 | 800-1550 | 4.2 | 120 | G1" | 14 |
BIG AC SOLAR PUMP (Huge Stainless Steel Solar Pump)
| Model | Impeller Mertial | Voltage (V) | Power (W) | Max. Flow (M³/H) | Max. Head (m) | Outlet (Inch) | Diameter* Length (mm) | Weight (Kg) |
| 6SPSC46-1 | Stainless steel | 380 | 3 | 68 | 15 | 4" | 138*885 | 47 |
| 6SPSC46-2 | 380 | 4 | 68 | 29 | 4" | 138*1056 | 52 | |
| 6SPSC46-3 | 380 | 5.5 | 68 | 44 | 4" | 138*1286 | 57 | |
| 6SPSC46-4 | 380 | 7.5 | 68 | 58 | 4" | 138*1444 | 62 | |
| 6SPSC46-5 | 380 | 7.5 | 68 | 69 | 4" | 138*1478 | 67 | |
| 6SPSC46-6 | 380 | 9.2 | 68 | 83 | 4" | 138*1602 | 68 | |
| 6SPSC46-7 | 380 | 11 | 68 | 93 | 4" | 138*1779 | 72 | |
| 6SPSC46-8 | 380 | 13 | 68 | 108 | 4" | 138*1902 | 82 | |
| 6SPSC46-10 | 380 | 15 | 68 | 134 | 4" | 138*2178 | 91 | |
| 6SPSC46-12 | 380 | 18.5 | 68 | 161 | 4" | 138*2479 | 104 | |
| 6SPSC46-14 | 380 | 22 | 68 | 188 | 4" | 138*2780 | 116 | |
| 6SPSC46-15 | 380 | 22 | 68 | 202 | 4" | 138*2957 | 121 | |
| 6SPSC46-17 | 380 | 26 | 68 | 229 | 4" | 138*3311 | 133 | |
| 6SPSC46-20 | 380 | 30 | 68 | 269 | 4" | 138*3608 | 145 |
For many of other type Solar Pump........ Please contact us for more detailed !
The Solar pumpsystem Including : Pump , Controller / Inverter , soalr panels, water level sensors, cabels, solar panel bracket (the customers can order bracket in your local place), and other spared parts;
Solar Pump
We can produce more than 8000 set solar pump system each month, and more quantity if the DC submersible pump;
1. pump : 3 years;
2. controller / Inverter : 1 year;
3. It is also accepable tp provide the free accessories after the warranty, but clients need to pay for the transportation cost;
We have finished hundrends of Solar pump system in more than 40 countries about the world, by cooperating with our distinguished disctributors and and local agricaltural mistration around the world.
Packages Declaration :
1. All of our goods are packed by the standards wooden cartons complied with the exportation requirement;
2. Solar solar panel packages or the cartons more than 100 pcs can also packed by wooden pallet;
1. We need your solar pump catalogue ?
Answer : before we answer your question, please inform us : how many m3 /hr water do you need? also inform us your requirement for distance for H1 =? , H2= ?, H3= ? , H4 = ? ;
2. We need your pricelist for all the models ?
Answer : we dont present "pricelist" for a new customers, Because different pump material , different order quantity has different pricelist; right now, we can produce as metal , stainless steel 201, stainless steel 304, stainless steel 316 material for different market requirement around the world.
Attn. : You can just inform us your "target price" and detailed requirement , we will evaluate if we can produce for you.
3. We need your pricelist for whole pump system inclduing solar panel ?
Answer : we commonly make quotation only for pump , controller, inverter, and water level detectors, not included solar panels.
we only make total system quotation after you confirmed to order from us, since we are super busy and it takes long time to design the solar panel connection and calculated the price;
4. How many solar panels do we need for the pump ?
Answer : To design & calculate the perfect solar panel connection, you have to take concerned pump power, pump voltage, pump current requirement, we will design for you after you confirmed the order.
5 . Our common questions for the new customer's inquiry :
(1) How many pcs pump system do you need ?
(2) Do you need total system inclduing solar panel or just pump and controller ?
(3) Which transportation way will you select ? by air ? by Sea ? or by Door to Door express? (please inform us postal code in you need express);
NOTE : Please reply us for all the above question when you plan to give us inquiry , otherwise your iqnuiry will be ingnoured or not focused on.
