mini VMC430, mini CNC machine center VMC420, VMC450
X axis travel 450mm max.
Hiwin or PMI linear guides or regular boxways - slide guides both avail
Taiwan made spindle, NSK bearings,Hiwin ball screws
|
VMC420 |
X axis travel |
420mm |
Y axis travel |
300mm |
Z axis Travel |
400mm |
Spindle nose to table |
100-550mm |
Spindle center to column guiderail |
383mm |
X axis fast speed |
36m/min |
Y axis fast speed |
36m/min |
Z axis fast speed |
24m/min |
Feeding rate |
1-12000mm/min |
Table size |
300×700mm |
Max loading on table |
200Kg |
T-slot |
3-16-110mm |
Spindle speed |
80-8000rpm |
Spndle taper (7:24) |
BT40/ Ø120 |
Main motor |
3.7/5.5KW |
ATC type |
umbrella |
Tools quantity |
12-Tools |
Max dia of tool |
80/150mm |
Max length of tool |
300mm |
Max weight of tool |
7Kg |
Tool change |
12 seconds (max) |
Positioning accuracy |
±0.008/300mm |
Repositioning |
±0.005mm |
Machine weight |
2000Kg |
ISO9001, ISO14001 certified professional manufacturer, 5th year Golden supplier, high quality at much competitive prices.
Standard export packing, in ply wood cases or per customers
One year warranty.
After one year, cost rate parts and services.
We're ISO9001, ISO14001, CE certified professional manufacturer of CNC Lathes, CNC Machines centers from China.
