torn cnc machine
1. torn cnc machine CK6132 specification
| mini cnc turning mas |
unite | CK6132 |
| max. swing over bed | mm | 320 |
| max. swing over cross slide | mm | 90 |
| max. turning length | mm | collet400/ chuck 290 |
| thru-hole dia. of spindle | mm | 48 |
| drawing bar dia. | mm | 41 |
| spindle speed | rpm | 150-2500 |
| work piece clamping | collet and chuck | |
| main motor power | kw | 4 |
| invertor power | kw | 5.5 |
| x/z axis torque | N.m | 4/4 |
| x/z fast feeding speed | m/min | 8/10 |
| tool post type | 4 tool electric type | |
| tool bar section | mm | 16*16 |
| tailstock sleeve dia. | mm | 60 |
| tailstock sleeve travel | mm | 100 |
| tailstock sleeve taper | MT4# | |
| dimension | mm | 1750*1200*1570mm |
| mini cnc turning mas N.W. | kg | 1220 |
2.Standard accessories for CK6130 mini cnc turning mas
GSK980TDC or Siemens 808d NC system
inverter motor 4kw
spring collet
3.Optional accessories for CK6130 mini cnc turning mas
KND100Ti or Fanuc 0I mate-TD
servo motor 3.7/5.5 kw
inverter motor 5.5 kw
160mm manual chuck
160mm domestic thu-hole hydraulic chuck
160mm domestic none thru-hole hydraulic chuck
160mm domestic thu-hole hydraulic chuck (Taiwan brand)
160mm domestic none thru-hole hydraulic chuck(Taiwan brand)
4. Service of CK6132 torn cnc machine
1. engineers are available to do oversea machinery service. In some countries, we have oversea
agent doing after-sale service in time and professionally
2.24 hours heart to heart service on-line or mobile
3. training in our factory and on-line are free of cost
4. warranty is 12 months, small broken parts are free of cost to replace, spare parts are delivered
with machine for customer convenience.
5.We offer best agent price and distributer price.
5. Customer and delivery of CK6132 torn cnc machine
accept ODM, OEM,
accept FOB, CFR, CIF, EXW price,
T/T 30% as deposit and the balance before machine tools leave our factory,
normal products with standard configuration manufacturing time is 7-15 working days.
7.CE, ISO9001, ISO14001 certificates
8. Packing of CK6132 torn cnc machine
To choose the most suitable and economic CNC lathe model, please kindly tell the following
info. in details
piece material and usage, solid type or hollowed type ( pipe type),
2. list all of outer diameters and inner diameter,
3. drawings is best to be sent to us too.
4. special requirement
Click “send” now and learn more details of our products.
