Help CenterSingle Stage High Pressure Regulator - HPR 270 Series (SFT-1286)
Related Products
Specifications
Showcasing cum distribution partner for ABJ Engineering Private Limited (Gas Control Specialist).HPR 270 Series is cost effective product equivalent to Concoa 402 series, Tescom 44-2200 series, Go Regulator PR-2 series, Swagelok KPR series.
The HPR -270 series is a brass single stage pressure regulator recommended for use with high purity non-corrosive gases and gas mixtures which would be affected by the absorption and desorption of contaminants from a regulator with a non metallic diaphragm. It is suitable for all such application up to a maximum inlet pressure of 210 bar. Internal surface finish of body is better than 1.6µm with chrome plating as option which allows easier cleaning and lesser particle contamination.
FEATURES & SPECIFICATION
- Stainless Steel Diaphragm
- Standard 10 µm sintered Bronze filter at inlet of main valve assembly
- 1.6 µm internal surface finish as standard
- Cleaned for Oxygen service
- Bubbles tight shut-off
- Inlet pressure: 210 bar (3000 psi)
- Outlet range: 0 to 35 bar (500 psi)
- Flow Coefficient: Cv 0.06
- Design Pressure: 1.5 times working pr.
- All Connections: ¼" NPT (F)
- Seat: PTFE / PCTFE
- Max. Operating Temperature:
PTFE - 66 C
PCTFE - 80 C
- Inlet end connection: ¼” NPT (F)
- Outlet end connection: ¼” NPT (F)
