Specifications
ZLP630 powered suspended platformlift weight: 630kg
height: 100m
length: 6meters
height&voltage&length could design
New ZLP630 powered suspended platform
suspended platform: loading weight:200-1000kg,design the heigh,size, voltage,shap of platform for your all kinds of projects
Name |
Technical parameter |
||||||
Model |
ZLP500(5m) |
ZLP630(6m) |
4m |
3m |
2m |
||
Rated load |
500Kg |
630Kg |
500Kg |
500Kg |
500Kg |
||
Lifting speed |
8-10m/min |
8-10m/min |
8-10m/min |
8-10m/min |
8-10m/min |
||
Platform Dimension L×W×H(mm) |
5000(2m+3m)×720×1100 |
6000(1m+2m+3m)×720×1300 |
4000(2m+2m)×720×1300 |
3000(1m+2m)×720×1300 |
2000×720×1300 |
||
Lifting Height |
100 m |
100 m |
100 m |
100 m |
100 m |
||
Cable |
100 m |
100 m |
100 m |
100 m |
100 m |
||
Steel rope |
8.3mm |
8.3mm |
8.3mm |
8.3mm |
8.3mm |
||
|
Hoist |
Pulling power |
6.17KN |
6.17KN |
6.17KN |
6.17KN |
6.17KN |
|
|
Electric motor |
model |
YEJ90L-4 |
YEJ90L-4 |
YEJ90L-4 |
YEJ90L-4 |
YEJ90L-4 |
|
Power |
1.5KW*2 |
1.5KW*2 |
1.5KW*2 |
1.5KW*2 |
1.5KW*2 |
||
Voltage |
380V,3phase |
380V,3phase |
380V,3phase |
380V,3phase |
380V,3phase |
||
Rotational speed |
1420rpm |
1420rpm |
1420rpm |
1420rpm |
1420rpm |
||
Braking moment |
15Nm |
15Nm |
15Nm |
15Nm |
15Nm |
||
Safety lock |
Permission force of impact |
30KN |
30KN |
30KN |
30KN |
30KN |
|
Locking Cable Angle |
3°~8° |
3°~8° |
3°~8° |
3°~8° |
3°~8° |
||
Suspension mechanism |
Front beam overhang |
1.3~1.5m |
1.3~1.5m |
1.3~1.5m |
1.3~1.5m |
1.3~1.5m |
|
Support adjustable height |
1.44~2.14m |
1.44~2.14m |
1.44~2.14m |
1.44~2.14m |
1.44~2.14m |
||
Counterweight |
1000kg |
1000kg |
1000kg |
1000kg |
1000kg |
||
20’ft container |
10sets |
9sets |
10 sets |
11sets |
11 sets |
||
40’ft container |
15sets |
14sets |
16 sets |
17 sets |
18 sets |
||
l
