Specifications
Automatical electric actuator ball valve CTB series Large torque for water treatment projectActuator ball valve for automatic control,HAVC,water treatment
Technical parameters:
Voltage:AC220V,380V,50/60HZ
Actuator rotation:0-360/90 degrees
Torque of actuator:50-2000NM
Open/close time:10,20,30,60,100 sec
Electric machine:15W-100W
Metal gear, large output torque
Actuator weight:2.5kg-12kg
Manually operating: operated by disassembling type hexagonal handle
Waterproof performance IP-67
Installation angle: any angle
Material of main parts:
Actuator: aluminum alloy
Coupling: die-casting metal
Bracket:stainless steel
Body:stainless steel(304,316),UPVC
Ball seat: PTFE
Sealing: EPDM
NPT,flanged,welded connecting
Features:
The size of the actuator is only a quarter of average ones.Though samll in size,it has super torsion
Various kinds of body material are availbaler for choose,which can resist corrosion and high temperature
Product is designed with high level protection to IP67 level
Manual override function can prevent damage during power failure
