Wafer PTFE Butterfly Valve With Actuator

Wafer PTFE Butterfly Valve With Actuator thumbnail-1
Wafer PTFE Butterfly Valve With Actuator photo-1
US$ 1 - 500 MOQ: 1 Set
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Butterfly
Pressure:
Medium Pressure
Contact Supplier Request Quote Chat Now
Wenzhou Heli Automatic Meter Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard or Nonstandard Standard
Structure Butterfly
Pressure Medium Pressure
Power Other, Electromotion
Material Casting
Temperature of Media Medium Temperature
Media Water
Port Size 50Nm/60Nm/100Nm
Place of Origin Zhejiang, China
Model Number HL-10
Brand Name HELI



Model



HL-10

Power

DC12V

DC24V

DC220V

AC24V

AC110V

AC220V

AC380V

Motor power

40W,23W

Rated current

4.8A

2.4A

0.32A

3A

0.64A

0.24A

0.19A

Output torque

100Nm

50Nm/60Nm/100Nm

Action time

10S

13S/15S/20S/30S

Circuit control

B,S,R,H,A,K,D,T

Rotary angle

0-90°

Weight

4 Kg

Voltage-with standing value

500VAC/1min

1500VAC/1min

Insulated resistance

100MΩ/300VDC

100MΩ/500VDC

Protection class

IP67

Surrounding Temperature

-25°C~60°C(The other temperature can be customized)

Installation angle

Any angle

Case material

Aluminium die-casting components

Optional function

Overload protection, heater

Wafer PTFE Butterfly Valve With ActuatorWafer PTFE Butterfly Valve With Actuator
