01 BV 2.5mm PVC Stranded Bare BV Wire Company
US$ 0.001 - 99
MOQ: 6 Kilometers
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Winpower
Model Number:
BV 2.5mm2
Payment & Shipping
Payment Methods:
Port of Shipment:
Port of Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
01 BV 1.5mm PVC Solid Bare Copper Colourful bv WireUS$ 0.001 - 99MOQ: 6 Kilometers -
BV PVC Copper Buidling Wire 4mm WireUS$ 0.001 - 99MOQ: 6 Kilometers
-
PVC Solid Bare Copper BV 2.5mm2 House Wiring Electrical CableUS$ 0.001 - 99MOQ: 6 Kilometers
-
01 BV 1.5mm PVC Stranded Bare Copper Blue bv WireUS$ 0.001 - 99MOQ: 6 Kilometers
-
BV 4mm Copper Building WireUS$ 0.001 - 5MOQ: 6 Kilometers
Place of Origin
Jiangsu, China
Brand Name
Winpower
Model Number
BV 2.5mm2
Type
Insulated
Application
Other, Heating, home use
Conductor Material
Copper
Conductor Type
Stranded
Insulation Material
PVC
01 BV 2.5mm PVC stranded bare BV wire company
Rated temperature: 70 centigrade
Rated voltage:450/750V
Reference standard: JB/T 6213.6-2006
Conductor: solid bare copper wire 1/1.78mm
Insulation :PVC ,RoHS compliant
Uniform insulation thickness to ensure easy stripping and cutting
Generally it is applied into electrical equipment wire
| conductor | Insulation | Max.COND Resistance |
Dielectric Strength (VAC ,1 MIN) |
|||
|
Cross section (mm2) |
construction no (No./mm) |
dia (mm) |
Thickness (mm) |
O.D. (mm) |
||
| 1.5 | 1/1.38 | 1.13 | 0.70 | 2.40 | 12.1 | 3000 |
| 32/0.20 | 1.31 | 0.70 | 2.60 | 12.1 | 3000 | |
| 2.5 | 1/1.78 | 1.58 | 0.80 | 3.05 | 7.41 | 3000 |
| 49/0.25 | 2.02 | 0.80 | 3.06 | 7.41 | 3000 | |
| 4.0 | 1/2.25 | 2.60 | 0.80 | 4.10 | 4.61 | 3000 |
| 56/0.3 | 3.42 | 0.80 | 4.00 | 4.61 | 3000 | |
| 6.0 | 84/0.30 | 3.42 | 0.80 | 5.20 | 3.08 | 3000 |
| 10.0 | 84/0.40 | 4.56 | 1.00 | 6.30 | 1.83 | 3000 |
| 16.0 | 126/0.40 | 5.60 | 1.00 | 8.0 | 1.15 | 3000 |
