Specifications
gabion box stone cage1. Flood bank,Guiding bank
2. Economic&Fast delivery
3. Simple installation
4. No collapse&Durable
1. Introduction
Gabion Box Stone Cage
Gabion Box Stone Cage, uniformly partitioned, are wire made containers of various sizes. It is interconnected with other similar containers and filled with stones at the site of use to form flexible, permeable, monolithic structures such as retaining walls, sea walls, channel linings, revetments and weirs for earth retention. In order to strengthen the boxes, all the edges of structure are selvedged with wire of greater diameter.
Gabion Box Stone Cage is divided into cells by diaphragms positioned at approximately 1m centers.
The wire is heavily zinc coated and for protection it can also be PVC coated. Stainless steel wire is also available according to customers’ special order. Gabion Box Stone Cages are supplied in various sizes. 2m in length, 1m in width and 1m in height is the most popular size. The diameter of the wire used can also be varied.
Sizes:
Standard size: 6x2x0.17m 6x2x0.23m 6x2x0.30m 3x2x0.17m 3x2x0.23m 3x2x0.30m
Mesh size(mm): 60x80mm,80x100mm,100x120mm,120x150mm
Wire diameter: 2.2mm/3.2mm,2.4mm/3.4mm,2mm/3.0mm
(We can manufacture as client's demand.)
2. Specification
Length(m) |
Width(m) |
Height(m) |
Mesh type(mm) |
3m |
2m |
0.15-0.20-0.25 |
80x100 |
4m |
2m |
0.15-0.20-0.25 |
80x100 |
5m |
2m |
0.15-0.20-0.25 |
80x100 |
6m |
2m |
0.15-0.20-0.25 |
80x100 |
3m |
2m |
0.17-0.23-0.30 |
60x80 |
4m |
2m |
0.17-0.23-0.30 |
60x80 |
5m |
2m |
0.17-0.23-0.30 |
60x80 |
6m |
2m |
0.17-0.23-0.30 |
60x80 |
(All sizes and dimensions are nominal. Tolerances of ± 3% of the width, length, and ±2.5 cm of the height shall be permitted.)
3. Characteritics
C1. Economical. It only needs to load a stone cage that can be sealed.
C2. Construction is simple, without special skills.
C3. A strong withstand natural damage and corrosion resistance and resistance to adverse effects of climate.
C4. Withstand large-scale deformation, and does not collapse.
C5. Cage rock crevice between the mud to plant production, with the surrounding natural environment melting together.
C6. Has good permeability to prevent static fluid from the damage caused.
C7. Save transportation costs. Can be folded up and assembly on site.
4. Applications
A1. Waterways and Channels
A2. River Crossing
A3. Landscaping Retaining Structures
A4. Marinas and Seashore Protection
A5. Bridges and Culvert Protection
A6. Rockfall Protection
5. Packaging Photos
6. Customers Visiting and Certificates
7. Project Photos
8. Our services
S1. We can offer any sizes of gabion mesh, baskets or boxes according to the requirements of customers.
S2. We will reply you as soon as possible upon receving your request of your products.
S3. We can provide you with samples free of charge.
9. About Konson
Konson Industrial Company Limited, with more than 15 years production experience, becomes one of the leading manufacturers of the gabions, mattress and gabion production line in China. We would like to offer good service and excellent products to customers wholeheartedly!
Konson's workshop
