Specifications
PVC Coated 60x80cm Hexagonal Wire Mesh1 Hot dipped galvanized
2 Diameter:2.0-4.0mm
3 ISO,SGS,High quality
4 Fast delivery
1. Introduction
PVC Coated 60x80cm Hexagonal Wire Mesh(Manufacturer)
Hexagonal Wire Mesh offers good ventilation and fencing uses. It is made of twisted carbon steel wire, electro or hot dipped galvanized, then plastic coated, or plain.
Hexagonal Wire Mesh can be fabricated into gabions boxes – one of the most popular wire products for flood control. Then stones are put into them. Laying of hexagonal wire mesh makes up a wall or bank against water and flood.
Hexagonal Wire Mesh can also be welded into poultry netting for breeding of chicken and other poultry. It is popularly used as fences after green coated, and costs can be reduced. In the past years, hexagonal wire mesh is made of galvanized iron wire that has been used in fences, breeding and construction reinforcement.
A1. Retaining wall structures
A2. River and canal training works
A3. Erosion and scour protection
A4. Roadway protection
A5. Bridge protection
A6. Hydraulic structures
A7. Dams and culverts
A8. Coastal embankment works
A9. Rockfall and soil erosion protection
3. Wire specifications
Hexagonal Wire Mesh | |||
Opening |
Wire Diameter(Metal Wire) |
Wire Diameter (PVC Coate)/ |
Strands |
60X80 |
f2.0-2.8 |
f2.0/3.0-2.5/3.5 |
3 |
80X100 |
f2.0-3.2 |
f2.0/3.0-2.8/3.8 |
3 |
80X120 |
f2.0-3.2 |
f2.0/3.0-2.8/3.8 |
3 |
100X120 |
f2.0-3.4 |
f2.0/3.0-2.8/3.8 |
3 |
100X150 |
f2.0-3.4 |
f2.0/3.0-2.8/3.8 |
3 |
120X150 |
f2.0-4.0 |
f2.0/3.0-3.0/4.0 |
3 |
| Length | Width |
Height |
Diaphragm |
Volume |
Tolerance |
| 2.0m | 1.0m | 0.3m | 1 | 0.6m3 | |
| 3.0m | 1.0m | 0.3m | 2 | 0.9m3 | |
| 4.0m | 1.0m | 0.3m | 3 | 0.2m3 | |
| 2.0m | 1.0m | 0.5m | 1 | 1.0m3 | L+/-3% |
| 3.0m |
1.0m | 0.5m | 2 | 1.5m3 | W+/-5% |
| 4.0m | 1.0m | 0.5m | 3 | 2.0m3 | H+/-5% |
| 1.0m | 1.0m | 0.5m | 0 | 1.0m3 | |
| 1.0m | 1.0m | 1.0m | 0 | 1.5m3 | |
| 2.0m | 1.0m | 1.0m | 1 | 2.0m3 | |
| 3.0m | 1.0m | 1.0m | 2 | 3.0m3 | |
| 4.0m | 1.0m | 1.0m | 3 | 4.0m3 |
C2. Environment Friendly. Has less impact on the environment than concrete and other construction materials.
C3. Aesthetically Pleasing. Has a natural appearance and get further enhanced when combined with plants & vegetation growth.
C4. Durable. It ensures maximum strength and PVC coated wire offers double protection against corrosion.
C5. Adaptable. It is designed for flowing water in high velocity. Space among rocks helps to provide positive drainage.
C6. Strong. The solid material ensures that the units act as a strong monolithic structure.
C7. Flexible. Gabions can fit tight space and accommodate significant soil settlement. In freezing winter or thaw conditions, it has minimal impact to the structure.
C8. Low Maintenance. Gabions are virtually free in maintenance if erected and installed properly.
C9. Permeable. Resistant to hydrostatic pressure if built in marine environment.
5. Packing and loading
Hexagonal Wire Mesh Exported to Germany
7. Our Services
S1. We can offer any sizes of gabion mesh, baskets or boxes according to the requirements of customers.
S2. We will reply you as soon as possible upon receving your request of your products.
S3. We can provide you with samples free of charge.
Konson Industrial Company Limited, with more than 15 years production experience, becomes one of the leading manufacturers of the gabions, mattress and gabion production line in China. We would like to offer good service and excellent products to customers wholeheartedly!
