150w Portable Solar System

Name: 150w Portable Solar System
Brand: Vmaxpower
SKU: 118307783

US$ 99 - 499 MOQ: 5 Pieces

Key Specifications

Place of Origin:

Beijing, China

Brand Name:

Vmaxpower

Model Number:

MSS150

Beijing Multifit Electrical Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Beijing, China

Brand Name Vmaxpower

Model Number MSS150

Specification Normal

Application Home

Output Voltage (V) 110V/220V

Load Power (W) 1000w

Solar Power (W) 150W

Work Time (h) 6-8 Hours

Portable PV Power System

Specifications & Features:

1. All-in-one high integrated off-grid solar system.

2. Battery capacity power display.

3. Digital indication for PV charging & load power.

4. Automatic switch between PV generation and mains power (Optional).

5. PV power generation always preferred than mains power.

6. High-efficiency, easy-installation and reliable performance.

7. Pure sine wave output

8. Economic and environment-friendly

9. Overloading protection

10. Overheat protection

11. Short circuit protection

12. Over voltage protection

13. CE and Rohs certificates accredited.

Technical Data
Model		MSS1500Z	MSS3000Z	MSS5000Z
AC Output Power		1500W	3000W	5000W
Output Waveform		Pure Sine Wave
Precision of Output Voltage		220V±3% or 110V±3%
Precision of Output Frequency		50±3Hz or 60±3Hz
Power factor		0.99
Overload ability		120%, 30 seconds
Over Voltage Protection		>29V	>58V	>58V
Low Voltage Protection		<19V	<40V	<40V
Peak power efficiency		>94%
Switching time between PV power and mains power(Optional)		<4ms
Certificate		CE & RoHS
Operational Environment
Operating Temperature Range		-10~55℃
Relative Humidity		0~90%
Operating Altitude		0~4,000m
Standard Configuration details
No.	What’s included	MSS1500Z	MSS3000Z	MSS5000Z
1	Mainframe box	1PC L550W545H165 (mm)/19.50kg
2	Cell box	1PC	2PCS	3PCS
		L550W545H280 (mm)/15.50kg
3	Wheel	4PCS (Dia. 3 inch---H110mm)
4	Inverter	1500W	3000W	5000W
5	Controller	24V/45A	48V/60A	48V/60A
6	Poly Crystalline Solar Panel	1000W	2000W	3000W
		30.82V, 8.11A	30.82V, 8.11A	30.82V, 8.11A
		250W*4PCS	250W*8PCS	250W*12PCS
		L1640W992H40 (mm)/19.30kg
7	Lead Acid Battery	24V 140Ah	48V 140Ah	48V 210Ah
		12V 70Ah*4PCS	12V 70Ah*8PCS	12V 70Ah*12PCS
		L259W169H206(mm) Total H210mm/22.50kg
Mechanical Data
Dimension of System box (mm)		L550W545H555	L550W545H835	L550W545H1115
