750kg/1500Lbs Single Door Sliding Glass Door Lock with LED
Specifications:
| Product Parameter | Parameter Description |
| Lock Size | 280Lx81.6Wx46H(mm) |
| Armature plate | 190Lx70Wx13H(mm) |
| Holding Force | 750kg(1500Lbs) |
| Voltage | 12/24VDC+10% |
| Current Draw | 12V/420mA 24V/210mA |
| Optional Bracket | EL-750L, EL-750ZL |
| Signal Output | Dry Contact, Max Rating of Contact Current 3A |
| LED | red indicates the door is unlock, Green indicates the door is lock |
| Suitable for | Wooden door , Glass door ,Metal door , Fireproof door. |
| Surface Temp | ≤+20°C |
| Operating Temp | 10~+55°C(14-131F) |
| Suitable Humidity | 0~90%(non-condensing) |
| Finishes for Shell | Anodized aluminum |
| Finishes for Magnetic | Zinc |
| Finishes for Armature | Zinc |
| Weight | 5.9kg |
| Standard Packing | 4pcs |
Features:
Collinear Load Test 750kg, 1500pounds.
Dual Voltage 12 or 24 VDC (optional).
The Standard Voltage is 12VDC when Finished.
MOV Provides Reverse Current Protection.
Suitable For Wooden Door, Glass Door, Metal Door, Fireproof Door.
LED Indicates the Door Status
Lock Status sensor (NO/NC/COM)
Anti-Residual Magnetism Designed
High Strength Material, Anodized Aluminum Housing
Design without Mechanical Failure
Increase the holding Force, Dual Insulative Housing
Product Photo
Product Certification
Our Factory
Our Advantage
1. Professional R&D department, can offer you OEM/ODM services;
2. Professional technique supports and good service;
3. We strictly control the quality and regard it as our base for existence! QC staffs make piece-by-piece checks for all products.
Products are conducted aging test for 72 hours.
4. Our products are chosen high quality materials and ensure the prophase stability.
5. Our products meet ISO, CE, FCC, ROHS certificates;
The MOQ
We accpet sample and bulk order, usually has No specific request. PLS contact our sales for details.
Payment Method
We accept Bank T/T, Paypal, Westerm Union, moneygram and Escrow.
Shipping Method
1. By Express courier, such as: DHL, Fedex, UPS, TNT, EMS... take about 3-7 days.
2. By Air or Sea shipment for heavy and big goods, take longer time differently.
3. By China post for small package, take about 15-70 days.
Product Warranty
We provide 1~2 years warranty from the date of delivery but lifetime technical support.
