Help CenterHowo 6*4 Dump Truck/Tipper Truck
Related Products
-
JAC 3 Axle 6X4 Dump Truck/Tipper Trucks 20-30 TonUS$ 35,000 - 50,000MOQ: 1 Unit -
Dongfeng 6X4 Dump Truck/tipper TruckUS$ 30,000 - 40,000MOQ: 1 Unit
-
Beiben Truck For SaleNegotiableMOQ: 1 Unit
-
HOWO Dump Truck for Mine and RockUS$ 35,000 - 50,000MOQ: 1 Unit
-
C&C Dump Truck /tipper TruckUS$ 45,000 - 50,000MOQ: 1 Piece
| Item | Uint | Parameter | |||||||
| Dimension | Overall length | mm | 8,300 | ||||||
| Overall width | mm | 2,500 | |||||||
| Overall height | mm | 3,350 | |||||||
| Wheelbase | mm | 3625+1350 | |||||||
| Truck | Brand | Sino Truck ,HOWO | |||||||
| Truck Model | ZZ3257N3647B | ||||||||
| Wheel | 8.5-20,10 holes steel Disc wheel,11Pcs. | ||||||||
| Tire | 12.00-20 , 11Pcs | ||||||||
| Engine | WD615.69 Europe II ( made in china ) | ||||||||
| Engine power | 247kw (336hp ) | ||||||||
| Engine Capacity | 9726 | ||||||||
| Steering | ZF 8098 | ||||||||
| Transmission | HW15710 | ||||||||
| Driving axle | HC16 | ||||||||
| Axle-load | 7000kg/18000kg | ||||||||
| Brake | Air braking | ||||||||
| Max. Speed (Km/h) | 75 | ||||||||
| With air conditioner | |||||||||
| Structural weight ratting | Loading capacity | m3 | 15.5 | ||||||
| Tare weight | kg | 12,080 | |||||||
| Pay load | kg | 15,000 | |||||||
| G,V,W,R | kg | 27,080 | |||||||
| Cargo box | Dimension of cargo box | L:5600 x W: 2300 x H: 1200 (MM) | |||||||
| Lift system | "F" style | ||||||||
| Thickness of bottom plate | 8mm | ||||||||
| Thickness of side plate | 6mm | ||||||||
| Material | Q235 | ||||||||
| Loading capacity of cargo box | 15.5m3 | ||||||||
1. Why you choose us?
CIMC RUIJIANG is a special vehicle manufacturer that belongs to CIMC group .We have more than 10 years produce experience.And our company produces at least 300 varieties of special vehicles of more than 10 series.
2. How to trust us?
Following the business philosophy of our company which is“your partner for modern transportation”,the sales network of CIMC RUIJIANG has been covering China mainland and global markets including Asia, Africa, South America, East Europe, etc. and welcome visits our company at any time.
3. How about the delivery time?
Most of our trucks are all have in stock ,We can delivery to you within 7 days, if specially ordered , we always need around 30 days for production.
4.How do you ensure the quality of product?
Our Factory is standard production workship,got ISO CCC BV Certification,our workers are well trained. Our very product under goes a scrutinizing inspection process.
