Specifications
1.PES pleat filter element2.FDA listed materials
3.Manufacturer at factory price
4.In beverage industry
Manfre Supply PES Pleat Filter Element
---Professional Manufacturer
The polyethersulfone membrane provides high contaminant capacity,
superior flow rates and consistent removal of particles and microorganisms.
The cartridges are highly compatible with the most rigorous sanitizing methods
in the beverage industry. Reliability is further assured with the Manfre integrity
testable design.
Filter Specifications |
Dimensions / Parameters | |
|
Media Inner core, end caps, cage Support layers Gaskets/O-Rings Micron ratings
|
Nominal lengths
Outside diameter Inside diameter Surface area
|
Max. sustained operating bar) 15 psid @ 200F (1.03 bar @ 93C)
|
Performance Specifications
| Hot DI Water | Filter cartridge will withstand temperatures of 185F (85C) for up to 30 consecutive minutes. | ||
| Cleaning/Sanitization |
Compatible with most common chemical cleaning, sanitizing and sterilizing agents and with pH range from 1–14. Consult factory for specific compatibility information. |
||
| Steam/Autoclave | Cartridges may be steamed or autoclaved for at least 50 half-hour cycles @ 275F (135C). | ||
Typical Bacterial Retention Performance |
Pore Size | Retention | |
| 0.2 µm: | LRV for B. diminuta ≥ 7.8 | ||
| 0.45 µm: | LRV for S. marcescens ≥ 8.5 | ||
| 0.65 µm: |
LRV for S. cerevisiae ≥ 11 LRV for L. brevis ≥ 7.6 |
||
|
Integrity Test Specifications Minimum Bubble Point values and maximum Diffusive Air Flow (per 10-inch cartridge) values for Manfre filters wet with water: |
Pore Size | Bubble Point | Diffusive Air Flow |
| 0.2 µm: | ≥ 38psig (2.6 bar) | ≤ 35cc/min @ 30psig (2.1 bar) | |
| 0.45 µm: | ≥ 25psig (1.7 bar) | ≤ 35cc/min @ 20psig (1.4 bar) | |
| 0.65 µm: | ≥ 18psig (1.2 bar) | ≤ 35cc/min @ 15psig (1.0 bar) | |
Quality Assurance
Manufactured in an ISO Class 7 cleanroom environment
100% flushed with 18 MΩ-cm DI water and integrity tested
Meets USP Class VI Biological Test for Plastics
All materials are FDA listed for food and beverage contact
Repeatably steamable and sanitizable
High retention (LVR>7) of yeast and other spoilage organisms
Pore size, lot and serial number are stamped on each filter
element for identification and traceability
We have our own factory, Professional producing team.
Korea technology is adopted,Have rich export experience.
Special specifications can be produced by the customer's
requirements.
Welcome custom!!!
