API triplex mud pumpTriplex Single Acting mud pump
Mud pump for drilling rig
QZ3NB—1300 Drilling mud pump
QZ3NB-1300 drilling mud pump is the pump researched and manufactureed by Qingzhou petroleum machinery
factory . The design characteristics is an optimization parameter, it can increase the stroke properly,
lower the speed reasonably, improve the suction capability of the pump, and prolong the service life
of wearing parts .The pump is used for oil-field and other industrial and mining establishments; and also used for the drill, well workover and
transporting the liquid media.it is mainly installed on 25-45 rig.
The series pump are produced according to SY5138 of the petroleum industry standard strictly,
and carry through factory's experiment according to the standard.
QZ3NB—1300 Drilling mud pump technical parameter
Type |
Triplex Single Acting Piston Pump |
Stroke Length: |
305 mm |
Rated power |
1300HP (956KW) |
Suction inlet |
Φ300 mm |
Rated speed |
120 SPM |
Discharge outlet |
Φ102 mm |
Gear ratio |
4.194
|
Weights |
26800 Kg |
|
Pump Speed (SPM) |
Liner Size (mm) |
||||||||
130 |
140 |
150 |
160 |
170 |
180 |
||||
Theoretical Displacement (L/s) | |||||||||
120 |
24.27 |
28.16 |
32.52 |
36.18 |
41.52 |
46.54 |
|||
100 |
20.23 |
23.46 |
27.1 |
30.15 |
34.6 |
38.78 |
|||
90 |
18.21 |
21.12 |
24.39 |
27.13 |
31.14 |
34.90 |
|||
|
MPa Pressure Rating |
34.3 |
30.5 |
26.6 |
23.4 |
20.7 |
18.5 |
|||
Based on 90% mechanical efficiency and 100% volumetric efficiency.
Qingzhou Petroleum Machinery Factory Co., Ltd. wishes us
progress hand in hand and creates a brilliant future.
CONTACT: MS ANNIE
TEL: 86-15866595521
