X6140 HORIZONTAL MILLING MACHINE WITH DIVIDING HEAD FOR SALE

Name: X6140 HORIZONTAL MILLING MACHINE WITH DIVIDING HEAD FOR SALE
Brand: TZHISING
SKU: 122086547

US$ 1 - 10,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

TZHISING

Tengzhou Hising Machine Tools Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO PORT SHANGHAI PORT TIANJIN PORT

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name TZHISING

Model Number X6140

Type Horizontal

CNC or Not Normal

Voltage 380V/415V/220V

Power(W) 11KW

Dimension(L*W*H) 2556X2159X1770MM

Weight 3850KG

Certification ISO9001, CE

Warranty 12 MONTHS

After-sales Service Provided Engineers available to service machinery overseas

MAIN FEATURES OF X6140 HORIZONTAL MILLING MACHINE WITH DIVIDING HEAD FOR SALE:

1. CAST IRON OF HIGH RIGIDITY.

2. GUIDEWAYS QUENCHED AND FINE GRINDED.

3. DIFFERENT VOLTAGES REQUESTS ACCEPTABLE.

4. DIFFERENT COLORS REQUESTS ACCEPTABLE.

5. OEM SERVICE PROVIDED

MAIN SPECIFICATION OF X6140 X6140 HORIZONTAL MILLING MACHINE WITH DIVIDING HEAD FOR SALE:

Specification	Unit	X6140
Table size	mm	1700X400
No.of T-slots		3
Width of T-slots	mm	18
Max.load	kg	800
Longitudinal travel(manual/auto)	mm	900/800
Cross travel(manual/auto)	mm	315/300
Vertical travel(manual/auto)	mm	350/330
Table feed range(X/Y/Z)	mm/min	23.5-1180/23.5-1180/8-394
Rapid feed speed	mm/min	2300/2300/770
Spindle speed range	r/mm	30-1500
Spindle speed step	steps	18(steps)
Distance between spindle axis table surface	mm	30-380
Power of spindle motor	kw	11
Overall dimension(LXWXH)	mm	2556X2159X1770
Net weight	kg	3850
