Specifications
slip ringConvenient to assembly
High performa slip ring
Strict quality control system
Excellent post-sales
slip ring
We strive to meet the needs of our customers. If an assembly from above does not fit your requirements, our R&D team will work with you to design a slip ring to meet your exact demands.
Two years quality guarantee.
Customized Slip Ring
We strive to meet the needs of our customers. If an assembly from our standard line does not fit your requirements, our R&D team will work with you to design a slip ring to meet your exact demands.
Grand customized slip rings would reach below special requirements:
Current capabilities from nanoamps up to 1,000Amps
Voltage capabilities from microvolts up to 3KV
High speed up to 5,000 rpm
High temperature up to 400°C Low temperature up to -60°C(separate slip rings up to -150°C) Long life up to 200,000,000cycles 200million
Sealing up to IP67@1Mpa . Digital data transfer up to 600 Mbits/s Big bore size up to 1,000mm Multi-way up to 500 ways
Combine with electrical, signal, gas and liquid or fiber optical transmission.
Please provide us below information, we will provide the transmission solution according to your demands
No. of Circuit (Power & Signal)
Signal details if transfer signal Rated Current & Voltage per circuit Working Speed Working Temperature Operating Environment The way of Connecting Dimension if have limitation Protection Level
Application
Pack in carton or wooden case
BY DHL, FedEx, UPS or TNT
