PP Blowing Film Machine Features:
- XSJ-L series lower water-cooled film blowing machine employs lower blowing and self-overflowing method to produce products. The product is features by high transparency, good printing performance and adhesive.
- The extrusion system of the machine and the plasticization of the machine head have met the international advanced standard.
- Additionally, there are many types of equipment such as rotary machine head, static elimination and fully-automatic precise temperature control available for your choice. It is the ideal packing material for food, garment and other high grade products.
Main Technology Parameters
XSJ-L series lower water-cooled film blowing machine | ||||||
|
MODEL NO.
|
XSJ45-FMX500L |
XSJ55-FMX800L |
XSJ65-FMX1000L |
|||
|
LAYER NUMBER
|
1 |
|||||
|
MAX. FILM WIDTH
|
mm |
400 |
650 |
800 |
||
FILM THICKNESS |
mm |
0.02~0.12 |
||||
OUTPUT |
Kg/h |
35 |
50 |
65 |
||
RAW MATERIAL |
PP |
|||||
EXTRUDER | ||||||
SCREW DIAMETER |
mm |
Φ45 |
Φ55 |
Φ65 |
||
SCREW L/D |
28:1 |
25:1 |
||||
HEATER CAPACITY |
kw |
8.3 |
10.7 |
13.1 |
||
DRIVING MOTOR |
kw |
11 |
15 |
18.5 |
||
ROTATING DIE | ||||||
DIE DIAMETER |
mm |
Φ 150 |
Φ 250 |
Φ400 |
||
HEATER CAPACITY |
kw |
4.5 |
8 |
10.5 |
||
WATER COOLING RING |
cm |
10,12,15,17,20 25,30,32,35,40 |
25,28,30,35,40 45,50,55,60,65 |
35,40,45,50,55 60,65,70,75,80 |
||
COOLING AIR BLOWER |
kw |
0.55 |
0.75
|
|||
HAUL-OFF |
|
|||||
DRIVING MOTOR |
kw |
1.5 |
||||
TAKE-UP SPEED |
m/min |
10~55 |
||||
WINDER DRIVE MOTOR |
kw |
2.2 |
3.3 |
4.1 |
||
TEMPERATURE CONTROL |
point |
6 |
7 |
|||
WHOLE POWER WITH TOTAL MACHINE |
Kw
|
~ 28 |
~ 40 |
~ 49 |
||
SHAPE SIZE |
m |
4.0 X 1.3 X 3.0 |
6.0 X 1.8 X 3.6 |
6.7 X2.5 X4.2 |
||
WEIGHT |
t |
~ 2.8 |
~ 3.8 |
~ 4.5 |
||
Correct specifications depend on the actual model all specifications are subject to change without prior notice | ||||||
We are specialized in producing kinds of film blowing machine, bag making machine and other plastic film machine. If you have any interest in our products, welcome to contact me for more information.
