Specifications
PP Film Blowing Machine/Blowing Film MachinePP/LDPE/LLDPE Extruder machinery
Plastic Machinery
|
Polypropylene PP Plastic Film Extruder&Film Blowing/Blown Machine Water-cooled/Blowing Film Machine/Film blowing machine XSJ65-FMX1000L Features: XSJ-L series lower water-cooled film blowing machine employs lower blowing and self-overflowing method to produce products. The product is features by high transparency, good printing performance and adhesive. The extrusion system of the machine and the plasticization of the machine head have met the international advanced standard. Additionally, there are many types of equipment such as rotary machine head, static elimination and fully-automatic precise temperature control available for your choice. It is the ideal packing material for food, garment and other high grade products. Main Technology Parameters 1) LAYER NUMBER: one layer MAX. FILM WIDTH: 800mm FILM THICKNESS: 0.020-0.12 mm RAW MATERIAL: PP Output: 65 KG/H 2) EXTRUDER: SCREW DIAMETER: Φ65mm SCREW L/D: 25:1 HEATER CAPACITY: 13.1 kw DRIVING MOTOR: 22 kw
3) DIE: DIE DIAMETER: Φ400mm HEATER CAPACITY 10.5 KW COOLING AIR BLOWER: 0.75 KW
4) HAUL-OFF:
DRIVING MOTOR: 1.5 KW TAKE-UP SPEED: 10-55 m/min WINDER DRIVE MOTOR: 4.1 KW TEMPERATURE CONTROL: 7 units WHOLE POWER WITH TOTAL MACHINE: About 55 KW SHAPE SIZE: (L x W x H) 6.7 X2.5 X4.2 m WEIGHT: About 3500KG
|
