Vehicle Gps Tracker With CAN BUS

Vehicle Gps Tracker With CAN BUS thumbnail-1
Vehicle Gps Tracker With CAN BUS photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Gps Tracker
Use:
Automotive
Screen Size:
Other
Contact Supplier Request Quote Chat Now
Shenzhen Boshijie Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Gps Tracker
Use Automotive
Screen Size Other
Function Other, Other, Other, Tracking system
Place of Origin Guangdong, China
Brand Name BSJ
Model Number BSJ-A08G
Warranty 1 year

Specifications

A08G Tracker with OBD or OBDII
1.Built-in 4 relays
2.Record the total working time
3.Connect with CAN BUS

Specifications

A08G Tracker with OBD or OBDII
1.Built-in 4 relays
2.Record the total working time
3.Connect with CAN BUS

A08G Tracker with OBD or OBDII





module performance
Dual-Band 900MHz, 1800MHz(850/1900MHz optional)

260g

Workingl Voltage
DC 9V~36V

Normal power consumption
70mA (Power Saving Mode<20mA)

Working Temperature
-40~+85

Working Humidity
5%~95% RH

Antenna
GPS SMA connection, -26dB
GSM SMA connection, -3dB





vehicle gps tracker with CAN BUS





Interface
7 Digital Inputs (4 Positive Triggers & 3 Negative Triggers);
1 relay output 250mA 12VDC
2 output 200mA 12VDC (include camera power)
2 audio interface

Image function
Support 160 x 120, 320x 64, 480 x 240 resolution, max 200 pictures

Features of GPS Tracker
1.Real-time GPS tracking
2.Real-time vehicle status monitoring
3.Vehicle Immobilization Control
4.GPS mileage report and mileage pulse report(Traffic black box)
5.Blind area data storage, up to 50, 000 data log capacity
6.Geo-Fence with 108 rectangle area
7.Fleet management, 8 routes of vehicle tracking
9.Two audio interfaces for microphone and handset
10.Two RS232 interfaces for camera monitoring and information screen
11.More I/O interfaces for 19 User-Defined Report Alarm
12.Fuel and temperature monitoring via 2 analog inputs
13.Overspeed alerts
15.Smart power protection
16.Remote firmware upgrade via GPRS
18.Dual data communication capability through GPRS.
19.TCP/UDP dual mode communication





vehicle gps tracker with CAN BUS



Special Function:
1.Built-in 4 way relays and the antenna port from the internal device, make this device have great anti-broken function:A)If the antenna broken, it will control the machine arm or cut off oil&circuit function;B)If the SIM card out, it will control the machine arm or stop oil&circuit function;C)Main power off, control the machine arm or stop oil&circuit;
2.Record the machine vehicle's total working time and the longest working time;
3.Can connect with the original Canbus;
4.This is the customization products.



Configuration List



Standard

1.

Host of vehicle GPS terminal

1

2.

Owners Manual

1

3.

Warranty Card

1

4.

Certificate of Conformity

1

5.

Power cord

1 turns

6.

GPS       antenna

1

7.

GPRS/CDMA antenna

1

8.

Installation fittings

Several
