Home > Electrical & Electronics > Sensor > Pressure Sensor > FSCU1805 Series M18 3-Pins Inductive Proximity Sensors, Connector Type, Sensing Part Is Made of Metal, Full Metal Housing.
FSCU1805 Series M18 3-Pins Inductive Proximity Sensors, Connector Type, Sensing Part Is Made of Metal, Full Metal Housing.
US$ 5 - 10
MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
F&C
Model Number:
FSCU1805 series
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
8*8mm Front Sensing Field, 2mm Sensing Range, IP67, Dual LED, F3N-08TN02 Series Inductive Sensor.US$ 3 - 10MOQ: 20 Pieces -
8*8mm Sensing Field, 2mm Sensing Range, IP67, Dual LED, F3N-08DN02 Series Inductive Proximity Sensor.US$ 3 - 10MOQ: 20 Pieces
-
FKC2210 Series Sn10mm 12-24V dc Flat Capacitive Proximity Sensor With CEUS$ 12 - 22MOQ: 1 Piece
-
F&C M12 SN5mm PNP Capacitive Proximity Sensor With CEUS$ 10 - 17MOQ: 1 Piece
-
Q6 SN1mm 12-24V DC Small Square Inductive Proximity Sensor With CEUS$ 8.8 - 13.32MOQ: 3 Pieces
Place of Origin
Hunan, China
Brand Name
F&C
Model Number
FSCU1805 series
Usage
Position Sensor
Theory
Inductance Sensor
Output
Switching Transducer
Product Description
| standard shell/shield | FSCU1805-N/D R2M | NPN.NO | 5mm | 18×18×1(iron) | φ3×2M/3-wires |
| FSCU1805-N2/D R2M | NPN.NC | ||||
| FSCU1805-P/D R2M | PNP.NO | ||||
| FSCU1805-P2/D R2M | PNP.NC | ||||
| standard shell/non-shield | FSCU1808-N/D R2M | NPN.NO | 8mm | 18×18×1(iron) | φ3×2M/3-wires |
| FSCU1808-N2/D R2M | NPN.NC | ||||
| FSCU1808-P/D R2M | PNP.NO | ||||
| FSCU1808-P2/D R2M | PNP.NC |
| Response frequency | 1000Hz/800Hz |
| Hysteresis | 10%≤sensing distance |
| Operating voltage | DC:12~24VDC±10%/ can customize 5V |
| Current consumption | DC:≤8mA No—Load |
| Load current | DC:24V 150mA Max |
| Leakage current | DC:≤0.01mA no-Load |
| Residual votage | DC:≤1.5VDC No-load |
| Operating temperature | -20°C~+70°C |
| Material | PBTand SUS304 |
| Wiring method | 2M/3-wires |
| Protection degree | IP67 |
Diagram
