Home > Tools & Hardware > Pneumatic Tools > Pneumatic Wrench > HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice

HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice

HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice thumbnail-1
HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice thumbnail-2
HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice thumbnail-3
HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice thumbnail-4
HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice thumbnail-5
HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice photo-1
HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice photo-2
HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice photo-3
HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice photo-4
HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor Quality Choice photo-5
US$ 100 - 200 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Hongxin
Type:
Other, Air motor
Contact Supplier Request Quote Chat Now
Rudong Hongxin Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name Hongxin
Type Other, Air motor
Average Air Consumption 30cfm
Maximum Torque 2.2Nm
No-Load Speed 3000rpm

HX2AM 0.93HP Air Motor,Air Driven Pump Motor,Pneumatic Motor,Gast Equivalent



Known industry wide for their rugged construction and reliability,Hongxin air motors are used in a variety of applications.

Lubricated air motors come in seven basic models up to 9.5hp(7kw);motor speeds are variable from 300 to 10,000rpm.

Choose from hub,foot,face,flange interfacee mountings and clockwise,counterclockwise or reversible rotations.

Four and eight vane models are also available.



The main characteristics of air motor:



Variable speed

Nonelectrical sparking

Instantly reversible

Cool running

Compact and portable

Minimum maintenance

Will not burn out

Low price

Operate in all positions

Low shock starts

Self sealing vanes

Mounting flexibility

Four vane or eight vane

Long life accessories

Four and eight vane models are also available.



It can be operated in the tough environment which is damp, high-heat and excessive dust.



The air motors are widely used in drilling, ship, rock drilling of mining and chemical engineering etc.



Main technical parameters:

VANE AIR MOTOR

Model

Operation Data

Maximum Torque

Power

Torque

Rotate Speed

Air Consumption

Rotate Speed

Torque

hp

kW

Nm

lb.in

rpm

m³/h

cfm

rpm

Nm

lb.in

HX1AM

0.45

0.33

0.31

2.75

10000

35.1

20.5

650

0.65

5.60

HX1UP

0.45

0.33

0.58

5.25

6000

47

27

500

0.68

6.00

HX2AM

0.93

0.68

2.20

19.50

3000

49.5

30

350

3.05

26.10

HX4AM

1.70

1.30

4.10

36.00

3000

132.5

78

300

6.3

56.00

HX6AM

4.00

3.00

10.00

84.00

3000

228

128

300

13

115.00

HX8AM

5.25

3.90

14.40

132.00

2500

293

175

300

21

185.00

HX16AM

 9.50 7.00 34 290 2000 475 275 300 43 372



Photoes & Drawings For 2AM Air Motor:

HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic MotorHX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor

HX2AM-H FOOT MOUNTING                   HX2AM-V(GAST AIR MOTOR MODEL: 2AM-NRV-89) FACE MOUNTING

HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor

HX2AM-F110(GAST AIR MOTOR MODEL: 2AM-ARV-92) IEC #72 FLANGE MOUNTING

HX2AM-H 0.93HP Foot Mounting Air Motor,Air Driven Pump Motor,Gast Equivalent Pneumatic Motor

HX2AM-F114.3(GAST AIR MOTOR MODEL: 2AM-NRV-90) NEMA 56C FLANGE MOUNTING
