Help CenterAutomatic Filter Mesh Welding Machine
Related Products
-
Wire Well Screen Welding MachineUS$ 50,000 - 90,000MOQ: 1 Set -
Continuous Slot Well Screen Welding MachineUS$ 50,000 - 90,000MOQ: 1 Set
-
Metal Tube Filter Welding MachineUS$ 50,000 - 80,000MOQ: 1 Set
-
Cylinder Screen Welding MachineUS$ 30,000 - 90,000MOQ: 1 Set
-
High Strength Wedged Wire Screen Mesh Welding MachineUS$ 30,000 - 80,000MOQ: 1 Set
Specifications
Automatic filter mesh welding machine1.Panasonnic PLC and HMI
2.Imported famous elements
3.High precision,high automation
Automatic filter mesh welding machine
Automatic filter mesh welding machine
Model |
50—200mm |
100—600mm |
600—1200mm |
Power |
3Phase 380V 50Hz |
3Phase 380V 50Hz |
3Phase 380V 50Hz |
Rated capacity |
100KVA |
100KVA |
100KVA |
Slot distance |
≥0.1mm |
≥0.2mm |
≥0.25mm |
Canister length |
Max 6000mm |
Max 6000mm |
Max 4000mm |
Weld material |
Stainless steel wire & Low carbon steel wire |
||
V-wire size |
1.8—5.0mm |
1.8—5.0mm |
1.8—5.0mm |
Support rod size |
1.8—5.0mm |
1.8—5.0mm |
1.8—5.0mm |
Overall dimension |
13000*1500*3300mm |
13000*1600*3400mm |
11000*2100*3800mm |
Weight |
10000KG |
11000KG |
13000KG |
Automatic filter mesh welding machine
1. Our filter mesh welding machine has the advantage of easy operation, low noise, high efficiency.
2. The main axis and feeding axis adopt Panasonic Brand AC power servo motor and drivers.
3. The slot size is accurate and can adjust within range.
4. PLC and HMI control system make the machine easy to operate with the touch screen
