Use :
With PLC Full-computer Automatic Control produced by German Siemens Co.,this system has friendly man-machine interface, screen cue operation and graphicparameters. Data can be input by simple touch keyboard.
Technological parameters can be automatically memorized, so you only need to touch the Menu Key for the next production.
Control System:
With PLC Full-computer Automatic Control produced by German Siemens Co.,this system has man-machine interface, screen cue operation and graphic parameters. Data can be input by simple touch keyboard.
Technological parameters can be automatically memorized, so you only need to touch the Menu Key for the next production.
Features:
1.HMI screen cue, Siemens PLC control.
2.Solid and round grain, with uniform grain size and high product yield offer you with the best recovery.
3.Mixing and granulation are finished in one step, the efficiency Is increased by 4 to 5 times.
4.Automatic discharge.
5.Smaller floor space requirement,and short cleaning time.
6.Save 15-25% dosages of adhesive andshorten drying time.
7.Totally closed production complied with GMP.
8.It can still obtain good effect when specific weight difference between main medicine, subsidiary medicine auxiliary materials are greater.
9.Jacket-kettle can be used to heat or cool the materials.
10.Spraying feature is designed to solve the problem of extractpowder granulation.
11.Low noise < 72 db
12.Space between kettle bottom and blade is small (0.3~1mm) to avoid deposit in kettle bottom completely.
| Main Technical Variables | |||
| Item | Unit | HLSG-200 | HLSG-600 |
| Total Volume | L | 300 | 600 |
| Operating Volume | L | 50-180 | 100-450 |
| Feeding Quantity | kg | 40-100 | 80-200 |
| Impeller speed | r.p.m | 6-230 | 5-160 |
| Motor Power | kw | 15 | 22 |
| Rotating Speed of cutter | r.p.m | 300-2850 | 150-1440 |
| Motor Power | kw | 5.5 | 7.5 |
| Overall Dimensions(LXBXH) | mm | 2115X1615X2350 | 2700X1565X2235 |
| Weight of Machine | kg | 1500 | 2500 |
| Control Cabinet | kg | 150 | 200 |
