High Effective Mixing and Granulating Machine

High Effective Mixing and Granulating Machine thumbnail-1
High Effective Mixing and Granulating Machine photo-1
US$ 20,000 - 25,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Function:
Sealing, Wrapping
Application:
Food, Other, Food, Machinery & Hardware
Contact Supplier Request Quote Chat Now
Green Air Shenyang I/E Corporation Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Function Sealing, Wrapping
Application Food, Other, Food, Machinery & Hardware
Packaging Type Bags
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 380V
Power 15 kw
Place of Origin Liaoning, China
Brand Name STOMWOOD
Model Number HLSG-300P
Dimension(L*W*H) 2115x1615x2350mm
After-sales Service Provided Engineers available to service machinery overseas

Useful:

It applies to the following industries.
1.Pharmaceutical Industry-Tablet,Capsule  Electuary.
2.Ceramic, Chemical, Cosmetics and Plastics Industries.
3.Food Industry.



Features:
1.HMI, Siemens PLC full computerized-control.
2.Solid  grain, with uniformgrain size and high product yield.
3.Mixing and granulation are finished in one step, so the efficiency is increased 4 to 5 times.
4.Totally closed production, according to GMP.
5.It can still obtain good effect when specific weight difference between main medicine and
auxiliary medicine as well as auxiliary materials are great.
6.Double-layer trough jacket-kettle can be used to heat or cool the materials.
7.Low noise < 72 db
8.Space between kettle bottom and impeller is small (0.3~1mm) to avoid deposit in kettle bottom
completely.



Main Technical Variables
Model Unit HLSG-300P
Total Volume L 300
Working Volume L 50~200
Feeding quantity kg 40~100
Impeller Speed r.p.m 6~230
Impeller motor power kw 15
Cutter rotate Speed r.p.m 1440/2840
Cutter motor Power kw 4.5/5.5
Total air supply Pressure Mpa 0.5~0.7
Air Consumption L/min 150
Cooling Water Pressure Mpa 0.1~0.2
Water Consumption L/min 20
Shaft  sealing  Water Air pressure Mpa 0.15-0.3
Machine Weight kg 1500
Overall Dimensions mm 2115×1615×2350
