Specifications
MUSILAND MD11 DAC & Headphone AMP amplifier 2010NEWQuality assurance, one year warranty
32Bit/192Khz
Color: Black
MUSILAND MD11 DAC DIGITAL STEREO 24/192 Audio DAC
Features:
USB 2.0 , optical, RCA coaxial, BNC coaxial, inpput 24Bit/192kHz digital singal.
Asynchronous USB2.0 High Speed HD-Audio Interface;
asynchronous cache successive approximation "Asynchronous FIFOs Step by Step Receiver" S / PDIF receiver algorithm, asynchronous serial high-speed dynamic buffer audio coding
algorithm "Asynchronous Dynamic FIFOs Serial Audio Frame Encode", high-definition audio for 24Bit/192kHz born of the times . They help of XILINX's FPGA, and high-speed DSP core embedded 200Mhz achieved. To ensure the integrity of audio data, high-quality sexual and a lot of computation.
participate in tuned "Colorful Sounds Audio Tech." Tone control technology, to make the sound of music taste and authenticity to the balance;
composed of 18 discrete transistors "Energy Headphone AMP. Level-I" headphone amplifier, you can drive 300 ohm headphones good, do not have to be configured independently of the headphone amplifier.
the latest technology, "μ-Noise Precision Power" of trace noise, precision power, in addition to the voltage to meet the needs of enthusiasts worldwide, will also provide a stable machine, clean power supply. ESD EMI interference and even the impact of the elimination of a clean, even in the city or around the high volatility serious industrial plant electrical interference, but also stable, reliable work, without sacrificing performance.
intelligent control, LCD display, full electronic control, and firmware upgrades via USB in order to improve performance or add additional features
specifications:
| digital input |
USB2.0 interface: 24Bit, high-speed 16Bit 32Bit, sampling, 44.1khz, depth, 88.2 kHz, 48kHz 96kHz kHz, 192kHz 176.4, sampling. RCA concentric, BNC coaxial, optical fiber, 24Bit 16Bit: sample depth, 48kHz and 88.2 44.1khz, kHz, 96kHz kHz, 192kHz 176.4, sampling. MMDI support system. MULINK high-definition digital interface, 24Bit 16Bit: 32Bit, sampling, 44.1khz, depth, 88.2 kHz, 48kHz 96kHz kHz, 192kHz 176.4, sampling. MMDI support system |
| Clock jitter (44.1khz) | PDIF S / 200PS, USB, MULINK less than 100PS the output circuit |
| Dynamic range | more than 116dB |
| Signal-to-noise ratio (A) | more than 116dB projects |
| Total harmonic distortion | less than 0.0005%. |
| Frequency response (20Hz ~ 20KHz) | + - 0.2 dB |
| RMS maximum level | 2V |
| Output impedance | Ω 10K and headphone output |
| Maximum level | 4V RMS |
| Impedance | 10 Ω |
| Power | 500mW/RL = 300 Ω |
