VSI Hight-efficiency Vertical Shaft Impact CrusherLarge capacity,stable running
Low consumption
easy maintenance,operation
VSI High-efficiency Vertical Shaft Impact Crusher
1 Brief Introduction
Based on Chinese present working conditions, VSIsand making machine is the latest product of our company which absorbed the advanced technology from German.It can provide the best material for the highway, railway, construction project and concrete mixing station etc. Lower cost and good performance decide that this kind of equipment is a preferred choice for artificial sand making or stone reshaping.
2 Operating Principle
The entire center feeding: Material falls into the feed hopper, then enters the high-speed rotary sling wheel from center feeding hole, which is speeded immediately in the sing wheel, The speed can reach several dozens times of the gravity acceleration. Then it is thrown out from the sling wheel. First, it is crusher with other rebounded material fell freely from the sling wheel. Then both of them are impacted to the material lining (rock-rock) or strike back block (rock-iron), rebounded and stroke to the top of eddy cavity in the inclined-up direction. Then it moves along deflection-down, and forms a continous material curtain with the material from the impellers passage. Just like this, the material is stroke, rubbed, crushed twice or more, then is discharged from the down discharging hole.
3 Main Technical Parameter
| Model | VSI-7611 | VSI-8518 | VSI-9526 | VSI-1140 | VSI-1145 | |
| Capacity |
Cascade and Center Feeding |
120-180 | 200-260 | 300-380 | 450-520 | 490-600 |
| Center Feeding | 60-90 | 100-130 | 150-190 | 225-260 | 250-310 | |
| Feeding Size(mm) | Soft Material | <35 | <40 | <45 | <50 | <50 |
| Hard Material | <30 | <35 | <40 | <45 | <45 | |
| Rotation Speed (r/min) | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | 1180-1280 | |
|
Power of the Double Motors(kw)
|
110-150 | 180-220 | 264-320 | 400-440 | 440-520 | |
|
Overall dimension(mm) L×W×H |
3700x2150 x2100 |
4140x2280 x2425 |
4560x2447 x2278 |
5000x2700 x3300 |
5100x2790 x3320 |
|
| Weight (t) | 9.8 | 13.5 | 16.8 | 25.6 | 27.5 | |
| Power | 380V:50HZ | |||||
| Vibrating Sensor |
Inspection Scope: 0.1-20mm/s,it can be adjusted continuously |
|||||
|
Hydraulic Lubrication Station |
Power of Double Oil Pump |
2x0.31kw | ||||
| Safety |
Double oil pumps make sure supply of oil with; Stop automatically without oil flow or oil pressure; Water cooled; Heating start the motor in winter. |
|||||
| Overall Dimension(mm) | 820x520x1270 | |||||
| Power of Oil-box Heater | 2kw | |||||
4 Performance Features
4.1 Simple structure, low running costs. Stone by stone crushing principle of wear.
4.2 Hihg crushing rate, energy saving
4.3 With crushing, coarse grinding function
4.4 Moisture content of materials subject to little effect, moisture content of up to about 8%
4.5 Suitable for crushing medium-hard, special hard materials
5 Photo Gallary
