Home > Electrical & Electronics > Telecommunication & Broadcasting > Radio & TV Broadcasting > Digital TV DVB-T2 RF Modulator

Digital TV DVB-T2 RF Modulator

Name: Digital TV DVB-T2 RF Modulator
Brand: CEKE
SKU: 126423119

Digital TV DVB-T2 RF Modulator thumbnail-1

Digital TV DVB-T2 RF Modulator thumbnail-2

US$ 1 - 8,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangxi, China

Brand Name:

CEKE

Model Number:

CKDVB-T2

Contact Supplier Request Quote Chat Now

Guilin CEKE Communication Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou/Shenzhen China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangxi, China

Brand Name CEKE

Model Number CKDVB-T2

About Our Product

Digital TV DVB-T2 RF Modulator

CKDVB-T2

Product Introduction

A. Multi-standard capability: analog, DVB-T/H, DVB-T2, ATSC, ISDB-T/Tb

B. Dual cast capability: digital tv and analog tv in the same exciter

C. Available in UHF IV/V and VHF band I & III

Specification

OPERATION SPECIFICATIONS
Environment
Operating Temperature	-10 ~ 50℃
Atmospheric Pressure	≤ 95%
(MER)	86 kPa ~ 106 kPa
Power Supply
Voltage	88 ~ 264 VAC
Frequency	50 / 60 Hz
Inputs/Outputs
RF IN A /RF IN B	(AGC RF Feed-Back option via RF IN A)
Connector	BNC female
Impedance	50 Ω
Level	-30 dBm ~ 0 dBm (Recommended range: -15 dBm ~ -5 dBm)
Location	Back Panel
AGC IN (AGC DC Feed-Back option)
Connector	BNC female
Impedance	50 Ω
Input Type	DC Voltage 0 V ~ 5 V
Location	Back Panel
RF Output
Connector	N-type female
Impedance	50 Ω
Level	-25 dBm ~ +5 dBm
VSWR	> 15 dB
Location	Back Panel

Application

Production Flow

Packing & Shipping

Our Company

Company Introduction

Company file
Since established in High-tech Information Industrial Park Guilin, China in 2000, Guilin CEKE Communication Equipment Co., Ltd is dedicated in R&D, manufacturing, sales, engineering, technical support and after-sales service of MMDS transmitters, digital TV transmitters/repeaters as well as TV and radio microwave transmission equipment for radio &TV broadcasting. Our products have been certified by ISO9001 and got more than 10 patents, and have been exported to customers in 40 countries and regions Europe, America, Central Asia, Southeast Asia, Africa and Oceania.

We are not only provider of equipment but also a global provider of integrated solution for pay-TV broadcasting. We have successfully DTTV system integration projects countries like Sri Lanka, Kyrgyzstan, Costa Rica, Madagascar, Vanuatu and Equatorial Guinea.
