HGD Laboratory Plastic pipe Ring Stiffness Tester
Application:
This machine is mainly used for various pipe ring stiffness, flexibility and flat, central test, based
on customers ' special needs can also increase tensile, compression, bending, and functional
tests, is a multifunctional electronic universal testing machine
Feature:
1. The inner diameter not rule of tube,add wall thickness deformation measuring device to measure inside diameter deformation, high measurement accuracy, accurate and reliable control.
2. Digital display by micro controller data acquisition and processing is completed, LCD display of the test, the amount of deformation and compression speed and be able to print record.
Technical Parameter
Model |
HGD- 10 |
HGD- 20 |
HGD- 50 |
HGD- 100 |
HGD- 200 |
Max test force(KN) |
10 |
20 |
50 |
100 |
200 |
Test range |
2%~100% FS |
||||
Force accuracy |
Better than ±1% |
||||
Displacement accuracy |
Better than ±1% |
||||
Displacement resolution(mm) |
0.01 |
||||
Deformation test accuracy |
Better than ±1% |
||||
Deformation resolution |
0.01 |
||||
Test speed(mm/min) |
0.05-500 |
0.05-300 |
|||
Speed accuracy |
Better than ±2% |
||||
Max test tube diameter |
0~3000mm |
||||
Max test width |
>20% of the max tube diameter |
||||
Power |
1.5KW, 220V±10% |
2.5KW, 380V±10% |
|||
standard |
GB,ISO,ASTM etc. |
||||
Laboratory Plastic pipe Ring Stiffness Tester
CE Certificate
