Help CenterPipes and Tube Computer Control Ring Stiffness Tester
Related Products
-
Digital Ring Stiffness Tester,Ring Stiffness Universal Testing MachineUS$ 3,000 - 5,000MOQ: 1 Set -
Computer Control Ring Stiffness Testing EquipmentUS$ 6,500 - 8,000MOQ: 1 Set
-
MHH-5 Wood-based Panel Plywood Scratch Resistance TesterUS$ 300 - 1,000MOQ: 1 Set
-
MHH-5 Wood Scratching Resistance Machine/Wood Scratch Resistance TesterUS$ 99 - 9,999MOQ: 1 Set
-
Computer Control Man-made Board Tensile and Compression Testing MachineUS$ 5,000 - 7,000MOQ: 1 Set
Specifications
1.usage:ring stiffness test2.electric loading
puter auto control
4.with CE certificate
ring stiffness testing equipment
Application:
This machine is mainly used for various pipe ring stiffness, flexibility and flat, Central test, based on customers ' special needs can also increase tensile, compression, bending, and functional tests, is a multifunctional electronic universal testing machine.
Technical parameter:
Model |
HGW-20 |
HGW-50 |
HGW-100 |
Max test force(KN) |
20 |
50 |
100 |
Comperssion space(mm) |
0-800 |
||
Test width |
400(mm) |
450(mm) |
|
Test range |
2%~100%FS |
||
Test force accuracy |
Better than±1% |
||
Deformation accuracy |
Better than ±1% |
||
Deformation test range |
2%-100% |
||
Force speed |
0.05%~100%FS |
||
Force speed control precision |
Better than ±1% |
||
Displacemnt speed |
0.05~500mm/min |
0.05~200mm/min |
|
Displacement test resolution |
0.005 |
||
Displacement constant speed control accuracy |
Better than ±1% |
||
Patterned deformation control |
0.05%~100%FS |
||
Patterned deformation control accuracy |
better than ±1% |
||
Power |
220V±10%,50Hz |
||
Weight (Kg) |
450 |
550 |
|
Features:
1. The inner diameter not rule of tube,add wall thickness deformation measuring device to measure inside diameter deformation, high measurement accuracy, accurate and reliable control.
2. Digital display by microcontroller data acquisition and processing is completed, LCD display of the test, the amount of deformation and compression speed and be able to print Record.
