Specifications
Name:High Shear emulsion pumpMax flow:140M3/H
Type:BRL1
Power:1.5--185KW
20 years specialized manufactuer
1. Main Features
a. Inline High Shear Dispersing Emulsion Pump consists of one set of precision engineered stator and rotor inside the chamber.
b. The strong centrifugal forces generated by the high speed rotation rotor absorb the materials into the working chamber of the rotor and stator from axial direction.
c. All the materials dispersed, sheared and emulsified by the multi-layers Stator & Rotor and then ejected from the axial direction.
d. Stable finished products with high quality are produced after one time circulation or times.
2. Reference Parameter
a. Power Supply: 380V, 50/60Hz.
b. Seal: Dual End Mechanical Seal ( Pressure Balance Device is optional.)
c. Materials: The part contacting with materials is SS304 or SS316L.
d. Speed: 0-2930 rpm Frequency Converter Control ( Some Model can be customized up to 6000rpm).
e. Flux: 0.5-80 m3/h.
f. Outlet Pressure:≤0.3 MPa.
g. Pipeline Connection: Flange, Quick-connection or Screw
h. Package: Standard Package (Wooden Package).
1.Technical parameter
Model |
Power(kw) |
Capability(m3/h) |
Rotate speed (r/min) |
Entry diameter |
Exit diameter |
YX401/1/2 |
1.1 |
1 |
2900 |
Dn40 |
Dn |
YX401/1/4 |
1.1 |
1 |
2900 |
Dn40 |
Dn |
YX405/1/2 |
4 |
5 |
2900 |
Dn50 |
Dn50 |
YX405/1/4 |
4 |
5 |
2900 |
Dn50 |
Dn50 |
YX410/1/2 |
7.5 |
7 |
2900 |
Dn50 |
Dn50 |
YX410/1/4 |
7.5 |
7 |
2900 |
Dn50 |
Dn50 |
YX410/1/6 |
7.5 |
8 |
2900 |
Dn50 |
Dn50 |
YX425/1/2 |
18.5 |
10 |
1440 |
Dn80 |
Dn65 |
YX425/1/4 |
18.5 |
10 |
1440 |
Dn80 |
Dn65 |
YX425/1/6 |
18.5 |
10 |
1440 |
Dn80 |
Dn65 |
YX430/1/2 |
22 |
15 |
1440 |
Dn80 |
Dn65 |
YX430/1/4 |
22 |
15 |
1440 |
Dn80 |
Dn65 |
YX430/1/6 |
22 |
15 |
1440 |
Dn80 |
Dn65 |
YX450/1/2 |
37 |
15 |
1440 |
Dn150 |
Dn125 |
The above machine which we supply it to you, we can give you one years after sales warranty, we can also send our engineer to you factory to install this equipment and train your staff, but the Buyer should pay the round air ticket cost and arrange the hotel accommodation as well as the means for Seller’s engineer. We will send some free set of spare parts for you change it.
We can offer one-stop service for customers, which is product formula, raw material, packing material etc.
