Home > Electrical & Electronics > Electric Motor > Stepper Motor > 130BYG350A Microstep Stepper Motor
130BYG350A Microstep Stepper Motor
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
Microstep & Startshaphon
Model Number:
130BYG350A
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing Shanghai Shenzhen etc
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
130BYG350B Microstep Stepper MotorNegotiableMOQ: 1 Set -
130BYG350C Microstep Stepper MotorNegotiableMOQ: 1 Set
-
3-phase 110BYG350A Microstep Stepper MotorNegotiableMOQ: 1 Set
-
3-phase 110BYG350B Microstep Stepper MotorNegotiableMOQ: 1 Set
-
3-phase 110BYG350C Microstep Stepper MotorNegotiableMOQ: 1 Set
Place of Origin
Beijing, China
Brand Name
Microstep & Startshaphon
Model Number
130BYG350A
Phase
3
Type
Hybrid
Certification
ISO
Holding Torque
27Nm
Current / Phase
6.8A
Specifications
1.leading manufacturer of motor & driver in China2.famous trademark of "Microstep" & "Startshaphon" since 1992 in the world
130BYG350A
working environment:
-25 °C ~ +55 °C, 10~85% no dewing, no corrosivity, non-flammable and non-explosive, no electrical conductivity gas or liquid, no metal dust
insulation resistance: 500V DC 100MΩ Min
axial clearance: 0.1~0.3mm
radial run-out: 0.02mm max.
temperature rise: 85 °C max.
insulation strength: B
|
Model |
Type |
Current |
Driving |
Max. |
Line Resistance |
Line |
Weight |
Max. Starting |
Matching |
130BYG350A |
3-phase hybrid |
6.8A |
AC220V |
27Nm |
0.9Ω |
11mH |
11kg |
210 rpm |
MS-3H110M |
130BYG350B |
33Nm |
1.1Ω |
14mH |
13kg |
200 rpm |
||||
130BYG350C |
40Nm |
1.4Ω |
20mH |
17kg |
190 rpm |
