2016 Constant Temperature and Humidity Chamber lab Testing Machine
Temperature and Humidity Testing Chamber is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance, it is suitable for quality control of the industries of electron, electrical equipment, vehicle, metal, foodstuffs, chemistry, building materials, luggage, printing, packaging, etc.
| Environmental Temperature and Humidity Chamber/climate test chamber/machine/equipment | |||||||||||||||
| Secifications ( at +20ºC room temp. Or+25ºC water temp with empty load) | |||||||||||||||
| Model | KMH-R series | KMH-L series | KMH-S series | ||||||||||||
| 150R | 225R | 408R | 800R | 1000R | 150L | 225L | 408L | 800L | 1000L | 225S | 408S | 800S | 1000S | ||
| Temp. range | -20ºC~150ºC | -40 ºC~+150ºC | -70ºC~+150ºC | ||||||||||||
| Interior sizel | W(mm) | 600 | 700 | 700 | 1000 | 1000 | 600 | 700 | 700 | 1000 | 1000 | 700 | 700 | 1000 | 1000 |
| H(mm) | 600 | 700 | 750 | 1000 | 1000 | 600 | 700 | 750 | 1000 | 1000 | 700 | 750 | 1000 | 1000 | |
| D(mm) | 460 | 480 | 800 | 800 | 1000 | 460 | 480 | 800 | 800 | 1000 | 480 | 800 | 800 | 1000 | |
| Exterior size | W(mm) | 880 | 980 | 980 | 1280 | 1280 | 880 | 980 | 980 | 1280 | 1280 | 980 | 980 | 1280 | 1280 |
| H(mm) | 1730 | 1890 | 1940 | 2160 | 2160 | 1730 | 1890 | 1940 | 2160 | 2160 | 1890 | 1940 | 2160 | 2160 | |
| D(mm) | 1400 | 1460 | 1740 | 1750 | 1950 | 1400 | 1460 | 1740 | 1750 | 1950 | 1460 | 1740 | 1750 | 1950 | |
| Power(KW) | 5.8 | 6 | 7.5 | 12.8 | 12.8 | 7.5 | 7.5 | 8.5 | 14.5 | 14.5 | 9.5 | 10.6 | 18.5 | 18.5 | |
| Weight(KG) | 240 | 280 | 400 | 500 | 580 | 250 | 300 | 420 | 530 | 600 | 330 | 450 | 550 | 650 | |
| Humidity uniformity | ±3.0%R.H | ±5.0%R.H | ±3.0%R.H | ±5.0%R.H | ±3.0%R.H | ±5.0%R.H | |||||||||
| Heat up time | -20ºC~+100ºC,within 35 min | -40ºC~+100ºC, within 45 min | -70ºC~+100ºC,within 60 min | ||||||||||||
| Pull down time | +20ºC~-20ºC, within 45 min | +20ºC~-40ºC , within 60 min | +20ºC~-70ºC,within 80 min | ||||||||||||
| Standard accessories | Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m | ||||||||||||||
| Safety device (standard) | No fuse breaker, over pressureover heat and over current protection for compressor, | ||||||||||||||
| Over temp. protect, over load protect of blower, dry heat protection | |||||||||||||||
| Control System | Balanced Temperature & Humidity Control System | ||||||||||||||
| Refrigeration system | Air Cooled (Water Cooled Type is option) | ||||||||||||||
| Hermetic compressor,Single stage refrigeration system | |||||||||||||||
| CFC-Free refrigerant(HFC-507/HFC-23) | |||||||||||||||
| Controller | Panel:7-inch LCD Touch panel, Chinese or English display selectable | ||||||||||||||
| Operation model :Program or fix point running | |||||||||||||||
| Memory capacity :120programs,1200steps, | |||||||||||||||
| All repeat 999 cycles, part repeat 99 cycles | |||||||||||||||
| Humidity Range | 20~98%R.H | ||||||||||||||
| Temp. constancy | ±0.5ºC | ||||||||||||||
| Humidity constancy | ±2.5%R.H | ||||||||||||||
| Temp. uniformity | ±2.0ºC | ||||||||||||||
| Interior material | Stainless Steel Plate(SUS 304) | ||||||||||||||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | ||||||||||||||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | ||||||||||||||
| Ambient Temp. | +5ºC~+35ºC | ||||||||||||||
| Wiring method | AC 380±10%50Hz ,3 phase 4 wires +Ground Wires | ||||||||||||||
|
Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available | |||||||||||||||
1)The separation of humidifier circuit from electric circuit improves safety and protects the circuit against the leakage of water supply line.
2)Available in Chinese and English LCD touch screen, easy operation and program.
3)Able to display the relative date and information of the whole operating system in running mode, graphic display. precautions, maintenance and troubleshooting appear on the screen instantly.
4)The Sirocco fan motor provides greater cyclic airflow to avoid dead corner in the chamber so as to obtain an uniform distribution of temperature and humidity.
5)The system of heating up, heating down, dehumidifying, and humidifying can be operated independently so as to reduce the cost of testing, extend the operating life of the machine and decrease the failure rate.
6)Water Supply adopts automatic watering System, Circulating water supply together with water filter.
Compressor
Name: Bock Compressor
Brand: Bock(GEA)
Original: Germany
KOMEG use imported compressor from Germany with high efficiency low energy consumption, low noise.
Electronic components 1
Name: Electric cabinet
Brand: Schneider, DANFOSS, Omron, Panasonic
Original: GGermany, France, Japan
KOMEG use top brand electronics, with full range of protection include overheat of blower fan motor, earth leakage protection, load short circuit protection, over temperature protection, over pressure protection and so on.
Electronic components 2
Name: Oil seperator
Brand: EMERSON
Original: USA
Control System
Name: Controller
Brand: KOMEG/SAMWON
Original: China/South Korea
It can control temperature and humdity constantly such as thermo-hygrostat mounted on, termperature, humidity, respectively, by setting the PID values for each interval can be precisely controlled and easy control via PC or mobile is possible.
- High qualitty,Long life time and Competitive price
- Best after service:Professional R&D and technical team support,can make OEM & ODM order,and also can provide overall laboratory solutions,and good service.
- Strict quality control,more than 24hours befroe shipping and with 1year warrant
- With CE,ROHs,SGS and ISO certificates
- Fast response to your inquiry
Many other chambers for reference:
Environmental Climatic testing Chamber/ Temperature And Humidity Testing Chamber
Temperature/ humidity/ vibration three integrated Chamber
Rapid Temperature Change Chamber
3-zone/ 2-zone Thermal Shock Chamber
Walk-in Temperature And Humidity Chamber/ walk-in room
Precise Drying Test Chamber
Vacuum oven/ no oxidation oven
Burn-in Room
Salt spray Chamber
Vibration Testing Machine( mechanical and electromagnetic)
Aging test room
