Specifications
This machine is mainly used for continuous horizontal cutting of multi foam blocks .Foam Carrousel Slice Horizontal Cutter Machine
Foam carrousel slice horizontal cutter machine main application and performance:
This machine is mainly used for continuous horizontal cutting of multi foam blocks .Its feature as: the most advanced inverter speed controller technology , fully diigital controlling , accurate cutting ,high reliability ,high work efficiency .The max. diamter can beφ10.5M(newly developped),it can continuous cut foam blocks at W2150×L4500mm.(Vacuum work table is optional).
Foam carrousel slice horizontal cutter machine technical Data:
MODEL |
BYPQ-60 |
BYPQ -70 |
BYPQ -100 |
Cutting foam size |
W1500XL2000XH12000mm(4PCS) |
W1500XL2000XH1200mm(5PCS) |
W1500XL2000XH1200mm(8PCS) |
Cutting foam size max |
W1500XL2000XH12000mm(4PCS) |
W2150XL3000XH1200MM(3PCS) |
W2150XL4500XH1200MM(3PCS) |
Total power |
7.94 KW |
8.74 KW |
10.2 KW |
Worktable turning speed |
0~3.5 r/min |
0~3.5 r/min |
0~3.5 r/min |
Blade length |
8940 mm |
10000 mm |
10240 mm |
Work table dia |
φ6 m |
φ7 m |
φ10.5 m |
Cutting thickness |
2~150 mm |
2~150 mm |
2~150 mm |
Maching weight |
3300 KG |
3500 KG |
3800 KG |
Maching external size |
L7500XW6000X2500 mm |
L8500XW6000X2500 mm |
L1150XW6000X2500 mm |
Basic info:
Description:
1. The primary source, short production cycle, product quality guaranteed.
2. We will provide a complete after-sales service, the machine packed in wooden cases.
