Help Center2011 Aluminum Bar With Diameter 50mm 100mm Temper T8
Related Products
-
23mm Aluminum Bar 2011 T8NegotiableMOQ: 5 Tons -
12 mm Aluminum Bar 2011 T451NegotiableMOQ: 5 Tons
-
6061 Aluminum Flat BarUS$ 3,500 - 5,000MOQ: 5 Tons
-
Aluminium Flat Bar With Alloy 2A11 2A12 LY12 2017 2024US$ 2,500 - 3,000MOQ: 5 Tons
-
Price of Aluminum Bar 6061 7075 T6US$ 2,500 - 3,000MOQ: 5 Tons
Specifications
aluminum bar alloy 2011Temper:T3 T4 T8.
Diameter:6-400mm
Length:Fixed ruler ,Double-ruler
Alloy 2011 Aluminum bar
2011 hard aluminum alloy is mainly suitable for drawing tube, cold working bar and cold workinging wires, mainly used for screw and requirements with good cutting performance of mechanical processing products. The tempers of the alloy are T3, T4 and T8;
T3: after solution heat treatment for cold working, then through natural aging to basic stable state; Applicable to solid solution heat treatment after cold straightening, flatten in order to improve the strength of products.
T4: natural aging after solution heat treatment to the stable state; Undertake no longer applies to is after heat treatment, cold working (can be straightened, leveling, but does not affect the mechanical properties of the limit) products.
T8: after solution heat treatment after cold working, and then on the condition of artificial aging; Applies to the cold working or straightening, leveling in order to improve the strength of the product.
ALLOY |
chemical composition (%) |
|||||||||||||
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Ni |
Zn |
Ti |
Zr |
Other |
Al |
|||
2011 |
0.4 |
0.7 |
5.0~6.0 |
- |
- |
— |
— |
0.3 |
Bi: 0.20~0.6 |
— |
— |
0.05 |
0.15 |
rest |
Pb: 0.20~0.6 | ||||||||||||||
Electrical Properties of the Alloy 2011 aluminum bar
ALLOY |
20°Cvolume conductance/%IACS |
20°C Electrical resistivity/nΩ·m |
20°C TCR /nΩ·m·K-1 |
electrode potential /V |
2011 |
T3,T4:39 |
T3,T4:44 |
T3,T4,T8:0.1 |
T3,T4:-0.39 |
T8:45 |
T8:38 |
T8:-0.38 |
Mechanical Property of the Alloy 2011 aluminum bar
alloy |
temper |
Modulus of Elasticity |
shear modulus |
yield strength |
Tensile Strength |
Elongation |
Poisson's ratio |
Hardness |
shear strength |
fatigue strength |
E/Gpa |
G/Gpa |
δ0.2/MPa |
σb/Mpa |
δ10/% |
μ |
HB |
σc/Mpa |
σ–1/Mpa |
||
2011 |
T3 |
70 |
26 |
296 |
379 |
15 |
0.33 |
95 |
221 |
124 |
T8 |
70 |
26 |
310 |
407 |
12 |
0.33 |
100 |
241 |
124 |
The Pictures of the aluminum bar
Specific requirement of embrassed patterns or specification can be discussed at your request ,we also supply other patterns ,like five bars ,diamond, finger,etc.
The package and transport of aluminum bar
About Us
Jinan Zhaoyang Aluminium Industry Co.,Ltd is located in the land of rose, Pingyin County in Jinan. Our products have passed the ISO2000 Quality System Certificate.
Our main products are aluminum sheet, aluminum coil, corrugated aluminum roofing sheet , embossed aluminum sheet/coil ,color coated aluminum coil/sheet ,aluminum foil, aluminum strip, aluminum wire ,aluminum tube and so on. Our products are exported to America, Africa and Southeast Asia, etc and also sold to over 180 medium and large enterprises in Zhejiang, Shanghai, Hangzhou, Wuhan, Shandong and northeast China.
If you are interested in our products, please contact us:
