Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > 16CH Standalone DVR With HDMI Output , Multilingual Support

16CH Standalone DVR With HDMI Output , Multilingual Support

16CH Standalone DVR With HDMI Output , Multilingual Support thumbnail-1
16CH Standalone DVR With HDMI Output , Multilingual Support photo-1
US$ 60 - 65 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Joney Technology
Model Number:
DVR-6216F
Contact Supplier Request Quote Chat Now
Shenzhen Joney Security Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Joney Technology
Model Number DVR-6216F

Specifications

--16ch performance
--2D1+14CIF or 16CIF
--1CH BNC Output ,1CH VGA Output,1*HDMI(1080P)
--4CH RCA Input,1CH RCA Output



Specification:

System
Main Processor Embedded processor
Operating System Embedded LINUX
Video
Input 16 channel, BNC
Standard NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
Audio
Input 4 channel, RCA
Output 1 channel, RCA
Two-way Talk Reuse audio input/output channel 1
Display
Interface 1 HDMI, 1 VGA, 1 TV, BNC(1.0Vp-p, 75)
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
Display Split 1/16
Privacy Masking 16 rectangular zones (each camera)
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Video/Audio Compression H.264 / G.711
Resolution D1/4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120)
  Extra Stream CIF(1~25/30fps)
Bit Rate 48~4096Kb/s
Record Mode Manual, Schedule(Regular(Continuous), MD), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection& Alarm
Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input 4 channel
Relay Output 1 channel
Playback & Backup
Sync Playback 1/16
Search Mode Time/Date, MD & Exact search (accurate to second)
Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode USB Device / Network
Network
Ethernet RJ-45 port (10/100M)
Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter
Max. User Access 20 users
Smart Phone iPhone, iPad, Android, Windows Phone
Storage
Internal HDD 2 SATA port, up to 4TB
Auxiliary Interface
USB Interface 2 ports (1 Rear), USB2.0
RS485 PTZ control
General
Power Supply DC12V/2A
Power Consumption 10W(without HDD)
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
Dimension(W×D×H) 1U, 324x243x52mm
Weight 2.5KG(without HDD)



 Hot!!!H.264 16CH 1U  Standalone 2D1+14CIF+HDMI CCTV DVR

16CH Standalone DVR with HDMI output , Multilingual support

 16CH Standalone DVR with HDMI output , Multilingual supportChoosen Joney, Choosen Professional!   High quality more competitive price !!!



Welcome to visit our website for detailed information

www.joneysecurity.en.china.cn





Our Services

  16CH Standalone DVR with HDMI output , Multilingual support

16CH Standalone DVR with HDMI output , Multilingual support
