High Density Server X6000 Chassis

High Density Server X6000 Chassis thumbnail-1
High Density Server X6000 Chassis photo-1
US$ 171 - 171 MOQ: 10 Units
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Blade
Max Memory Capacity:
Other, ≥ 64GB
Contact Supplier Request Quote Chat Now
ActForNet Technologies Inc.
Payment & Shipping
Payment Methods:
Port of Shipment:
HongKong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Blade
Max Memory Capacity Other, ≥ 64GB
Max Processors 2
Processor Main Frequency 3.2G
Processor Type Xeon
Brand Name Huawei
Model Number BC2MIFRAME00
Place of Origin Guangdong, China

X6000 chassis(2/4 node slots, 2 power slots),2U

The X6000 server is a high-density server designed for cloud computing, data centers, and Internet applications. With its optimized architecture, the X6000 offers high performance, rich server node options, and better energy efficiency, making the X6000 the ideal choice for large-scale server deployments.



Features

High computing density

Rich server node options

  • The X6000 provides four half-width server nodes and one full-width server node. The server nodes support Intel® Xeon® E3-1200 v2 series, Intel® Xeon® E5-2400/E5-2600 series, and Intel® Xeon® E5-2400/E5-2600 v2 series, ensuring optimal performance based on service requirements.
  • The X6000 also offers options for customized server nodes, as needed.

Excellent energy efficiency and control

  • The 80 Plus® Platinum PSUs provide up to 94% power efficiency under a 50% load, which reduces power losses and optimizes power utilization.
  • The X6000 comes with highly efficient fan modules and an optimized cooling architecture that isolates power air ducts from server nodes, increasing cooling efficiency and reducing energy consumption.
  • The X6000 uses various energy-saving technologies, such as fan speed control by location, intelligent fan speed adjustment, and intelligent CPU frequency adjustment, which further reduce power consumption. In combination, these features offer a green, energy-saving solution.



Specifications

Item X6000
Form factor

2U node server
Server node

Half-width server nodes: XH310 V2, XH311 V2, XH320 V2, and XH321 V2
Full-width server node: XH621 V2
I/O module

One removable I/O module with up to four PCIe 2.0 x8 slots
PSU

Two hot-swappable PSUs working in 1+1 redundancy mode
Options:
• AC: 750W, 800W, 1,200W
• DC: 800W
Fan module

Three fan modules working in N+1 redundancy mode
Power supply

110/220 V AC or −48 V DC
Operating temperature

XH310 V2 and XH311 V2: 5ºC to 40ºC
XH320 V2, XH321 V2, and XH621 V2: 5ºC to 35ºC
Certification

CCC, VCCI, CE, UL, FCC, RoHS
Dimensions

Height: 87.5 mm (3.44 in.)
Width: 448 mm (17.64 in.)
Depth: 760 mm (29.92 in.)
