Home > Electrical & Electronics > Breaker & Protector > Circuit Breaker > Vacuum Contactor for Substation 3.6kV Vacuum Switch 3 Phase Contactor

Vacuum Contactor for Substation 3.6kV Vacuum Switch 3 Phase Contactor

Name: Vacuum Contactor for Substation 3.6kV Vacuum Switch 3 Phase Contactor
Brand: Ghorit
SKU: 128389967

Vacuum Contactor for Substation 3.6kV Vacuum Switch 3 Phase Contactor thumbnail-1

Vacuum Contactor for Substation 3.6kV Vacuum Switch 3 Phase Contactor photo-1

US$ 1,100 - 2,500 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Ghorit

Model Number:

JCZ5-7.2

Contact Supplier Request Quote Chat Now

Ghorit Electrical Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Ghorit

Model Number JCZ5-7.2

Type Vacuum

Poles Number 3

JCZ5-3.6kV-200A/400A/630A

Introduction

VC3-3.6/200,400,630 series vacuum contactor is used in an AC. 50-60 Hz electric power system, with rated working voltage is 3.6kV, and rated current of 200A,400A,630A,for direct or romote on-off control and circuit-breaking control of the of the main load. It is especially suitable for the frequently operated electric control applications such as electric motors, transformer, etc. This series adopts integrated framework, before-and-after layout between the main circuit and controlling circuit, adopts electrical latch, and vacuum interrupter with glass or ceramic shell.

Model

VC		-				/			-
1	2		3	4	5			6		7	8

1. High-voltage AC vaccum contactor
2. Designed code
3. Rated voltage(kV)
4. Latching mode:J—machanical latch; D—electrical latch
5. G—high altitude; Y—movable type; None—basic type
6. Rated current(A)
7. Rated short-time withstand current(kA)
8. Vaccum shell materials: T—ceramic

Main technical specifications

Type form					EVC3-3.6
Raed work voltage			kV		3.6
Rated work current			A		200	400	630
Rated frequency			Hz		50/60
Rated thermal current			A		200	400	630
Rated making capacity			A		2000	4000	6000
Rated breaking capacity			A		1600	3200	4800
Limit breaking capacity			A		2000	4000	6000
Limit breaking capacity			A/S		2000/4	4000/4	6000/4
Operating cycle	Long time	Time/hr		300
	Short time	Time/hr		600
Method of operation					Non-Latched
Mechanical endurance			Ops.		1000000
Electrical endurance			Ops.		250000(AC-3)
					100000(AC-4)
Operation voltage			V		AC and DC 120,220
Closing time			ms		≤200
Opening time			ms		≤160
Power frequency withstand voltage	Main circuit	kV		18
	Secondary	kV		2
Auxiliary switch					3a+3b
