Pipe Thread Lathe Low Price for Process Oil Pipeline
US$ 10,000 - 18,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
CNC
Payment & Shipping
Payment Methods:
Port of Shipment:
Pipe thread lathe Qing Dao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Pipe Thread Lathe Low Price for Inner Tube Processing ThreadUS$ 10,000 - 18,000MOQ: 1 Set -
China 's CNC Lathe Manufacturers Pipe Thread LatheUS$ 10,000 - 100,000MOQ: 1 Set
-
Threaded Pipe nc Lathe, Ordinary Pipe Threading LatheUS$ 10,000 - 100,000MOQ: 1 Set
-
Threaded Pipe CNC Lathe, CNC Pipe Threading Lathe SupplyUS$ 10,000 - 100,000MOQ: 1 Set
-
Threaded Pipe CNC Lathe, Pipe Threading Lathe How Much MoneyUS$ 10,000 - 100,000MOQ: 1 Set
Condition
New
Type
Horizontal
CNC or Not
CNC
Automatic Grade
Automatic
Max. Swing Diameter
610mm
Place of Origin
Shandong, China
Brand Name
HaiShu
Model Number
CKG1322A
Voltage
220V/380V
Power(W)
7.5kw
Dimension(L*W*H)
2650*1450*1700
Weight
2800kg
Certification
CE ISO
After-sales Service Provided
Engineers available to service machinery overseas
CNC pipe thread lathe specification
CKG1322A CNC pipe thread lathe
Term |
Unit |
Specification |
Lathe Max swing diameter |
mm |
φ630 |
Maximum turning length |
mm |
1000 |
Maximum processing outside diameter of pipe |
mm |
φ219 |
Spindle bore |
mm |
φ225 |
Number of spindle speeds |
|
Servo Promise |
X/Z Servo motor torque |
N.m |
10/15 |
Chuck form |
|
Three-jaw chuck |
Chuck diameter |
mm |
φ500 |
Turret form |
|
Four-station ,Vertical |
Tool section size |
mm |
32×32 |
X/Z Rapid traverse |
m/min |
3/3 |
Tailstock quill diameter |
mm |
φ100 |
Tailstock quill stroke |
mm |
250 |
Tailstock sleeve taper |
|
MT5 |
Spindle center to the height of the rail |
mm |
315 |
Main motor |
|
Servo motor 11KW 3000r/min |
Machine weight |
Kg |
5500 |
Machine outline size (L × W× H) |
mm |
3600*1750*1900 |
CNC system |
|
KND100Ti/GSK980TA(Optional) |
