Contact Platform Support
Help CenterMiniature Sensors
US$ 3.5 - 35
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GOLDSHINE
Model Number:
AM2A
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
GOLDSHINE
Model Number
AM2A
Usage
Pressure Sensor
Theory
Resistance Sensor
Output
Other, Analog sensor/digital sensor
Products Specification:
Model: |
AM2A |
AM2A-K |
Capacity: |
15,50LB |
15,50LB |
Combined Error: |
0.1 |
0.1 |
Output Sensitivity: |
1.5±0.15mV/V |
1.5±0.15mV/V |
Non-Linearity: |
±0.1%F.S |
±0.1%F.S |
Repeatability: |
±0.1%F.S |
±0.1%F.S |
Hysteresis: |
±0.1%F.S |
±0.1%F.S |
Creep: |
±0.1 (3min)%F.S |
±0.1 (3min)%F.S |
Temp.Effect On Zero: |
±0.3%F.S/10°C |
±0.3%F.S/10°C |
Temp.Effect On Span: |
≤+0.3%F.S/10°C |
≤+0.3%F.S/10°C |
Zero Balance: |
±1.0mV/V |
±1.0mV/V |
Input Resistance: |
350±500Ω |
1100±100Ω |
Output Resistance: |
350±50Ω |
1100±100Ω |
Insulation Resistance: |
≥2000MΩ(50V) |
≥2000MΩ(50V) |
Excitation Voltage: |
≤6V |
≤6V |
Operation Temp.Range: |
-10--+40°C |
-10--+40°C |
Overload Capacity: |
150%F.S |
150%F.S |
Recommended Application: |
Fishing Scales |
Fishing Scales |
