Help CenterVFS5000FS Nut Packing Machine Line
Related Products
-
(VFS5000FS) Automatic Candy Packing Machine LineNegotiableMOQ: 1 Set -
VFS7300 for Paste, Sauce, Oil Etc Liquid Packaging MachineNegotiableMOQ: 1 Set
-
(VFS7300) Rice, Seeds & Nuts Automatic Packaging Machine LineNegotiableMOQ: 1 Set
-
(JS-40A) Automatic Counting Pills Packaging MachineNegotiableMOQ: 1 Set
-
Small Quantity Auto-Powder Packaging MachineNegotiableMOQ: 1 Set
Application:
The unit of machine is suitable for automatically weighing filling and packaghing granule, slice, roll or irregular shape material such as candy, cookies, dried fruit, potato chips, nuts, coffee beans, jelly, chocolate, pet food, etc.
Advantage:
1. Machine fully controlled by Siemens or Omron PLC & Touch-Screen
2. Various types of heating sealable laminated films namely PE/BOPP, CPP/BOPP, CPP/PET, PE/NYLON, Aluminum Foil based can be run on the machine.
3. Multiple languages such as English, Spanish and Korean etc
Technical Specification:
Bag type |
Pillow type bag;Gusseted bag (Option) |
|
Speed |
40 to 80 bags/min (depend on product characteristics) |
|
Bag Length |
50 to 340mm (2.0 to 13.4in) |
|
Bag Width |
80 to 260mm (3.1 to 10.3in) |
|
Reel Film Width |
≤540mm (21.2in) |
|
Film thickness |
0.04-0.12mm (40-120mic.) |
|
Reel Outer Dia. |
400mm (15.7in) |
|
Reel Inner Dia. |
75mm (2.9in) |
|
Voltage |
AC220V/50Hz, 1phase or Per customer specification |
|
Power Consumption |
VFS5000F packaging machine |
3KW |
10Muti-head weigher |
1KW |
|
Compressed Air Requirement |
0.6 MPa0.36 M3min |
|
Machine Size |
VFS5000F packaging machine |
L1650 x W1140 x H1650; (in):L65.1 X W44.9 X H64.9 |
10Muti-head weigher |
L1136xW950xH1100mm |
|
Machine Weight |
VFS5000F packaging machine |
800kg |
10Muti-head weigher |
310kg |
|
