Help CenterValvula Solenoide
US$ 2 - 10
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Control
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo or shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SLP Series Brass Solenoid ValveUS$ 15 - 180MOQ: 10 Pieces -
4V Series Pneumatic Directional 3 Position 5 Port Single Control Solenoid ValveUS$ 10 - 200MOQ: 10 Pieces
-
VDF Series Water Solenoid ValveUS$ 20 - 200MOQ: 10 Pieces
-
Lead Wiring Type Pneumatic ValveUS$ 10 - 200MOQ: 10 Pieces
-
Solenoid Valve, 2 Ways Solenoid ValveUS$ 10 - 200MOQ: 5 Pieces
Standard or Nonstandard
Standard
Structure
Control
Pressure
Medium Pressure
Power
Solenoid
Material
Plastic
Temperature of Media
Medium Temperature
Media
Gas
Port Size
1/8"
Place of Origin
Zhejiang, China
Model Number
VSV23-1.4mm
Brand Name
VPC
Specifications
Two-Position Three-Way miniature solenoid valveHigh quality low price low consumption
One year warranty
PIN or flying lead
Characteristics:
Two-Position Three-Way miniature solenoid valve
High quality low price
One year warranty
Low consumption(2.3w)
PIN or flying lead
Specifications:
| Model | VSV23-1.4LV | VSV23-1.4LH | VSV23-1.4LC |
| Working Medium | Clean Air(40µm filteration) | ||
| Acting Type | Direct Acting | ||
| Working Pressure | 0~0.7Mpa | ||
| Working Temperature | -5~50°c | ||
| Response Time | ≤20m/s | ||
| Max Acting Frequency | 20 times/s | ||
| Manual Operated Type | Button | ||
| Lubricate | No required | ||
| Heat Resistant Grade | F | ||
| Protective Class | IP65 | ||
| Standard Voltage | DC24V | ||
| Allawable Voltage Range | ±10% | ||
| Orifice | 1.4mm | ||
| Wattage | 2.3watts(with indicator light) | ||
| Plug Type | Vertical | Horizontal | Plug |
Also we can produce many special products base on clients' requirement.
VSV units valves will be more powerful.(2 links to 10 links)
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2009
Factory Size
1,000-3,000 square meters
Total Employees
101 - 200 People
