led color changing 50mm ws2801 pixel round ball
1. Individually control, 1PCS LED ball pixel & 1IC (ws2801)
2. 50mm diameter balls with white opaque diffuser giving 360 degree viewing, pitch customized.
3. You must use a 12V DC power supply to power this pixel, do not use higher than 13V
or you can destroy the entire pixel.
4. SPI signal is in parallel connection, avoiding all lights influenced by the failure of one light in serial connection
5. Connetors: 4PIN waterproof female and male connectors, DAT, CLK, DC12V+, GND-
6. addressable lights you can set to any color, or animate
7. Factory sales directly, good quality and price, offer 2 years warranty and quikly after-sale service.
8. Brand: iPixel LED
6leds/pcs 360 degree view pixel 50mm led
The waterproof 4pin connector male and female connectors
Showing picture
| Product Name | 50mm ball led pixel light |
| Model Number | P50V12-360 |
| IC Chip | WS2801 |
| LED Chip | Epister 5050 RGB LED Chip |
| LED Qty | Double-sided, 3LEDs/sid 6 leds/pcs |
| Voltage | DC12V |
| Wattage | 1.44W/PCS |
| Cover Color | ball milky cover |
| Connector | 4PIN waterproof male and female |
| PCB Board | Double-sided board, each board with 3LEDs |
| IP Rate | IP 33 |
| Cable Length | 20cm usually, also can be customized |
| Beam angle | 360 degree |
| Certification | CE,RoHS |
| Warranty | 2 years |
The excellent light and user-friendly designs make LED Pixel perfect for numerous applications, i.e cove
lights, back lights, Night Club lighting,Dance floor ceiling ,outdoor signage
They can be a good choice for lights for hotels, restaurants, night clubs, coffee / wine bars, shopping malls,
various shops, cinemas, beauty centers,etc
26mm 3leds/pcs pixel led
35mm 6leds/pcs pixel led
SPI signal: LED Strip+LED power supply +LED controller
DMX control: LED Strip+LED pwer supply+DMX Controller+DMX decoder
LED controller: T- series SD card controller, RF remote controller, DMX controller, Arduino...
(offline / PC online)
LED power suppply: Meanwell power supply, T- series, A- series power supply...
(waterproof / non-waterproof)
