500w 200rpm Low RPM Generator
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Xinchang
Model Number:
XCH-500
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
10KW Permanent Magnet GeneratorUS$ 2,000 - 2,500MOQ: 100 Pieces -
Sufficient Watts 5KW Permanent Magnet GeneratorNegotiableMOQ: 100 Pieces
-
Cheap Price 1KW Permanent Magnet GeneratorUS$ 700 - 800MOQ: 1 Piece
-
100w Permanent Magnet GeneratorNegotiableMOQ: 100 Pieces
-
Low Speed Permanent Magnet GeneratorNegotiableMOQ: 100 Pieces
Place of Origin
Shandong, China
Brand Name
Xinchang
Model Number
XCH-500
Type
Wind Power Generator
Specifications
True sufficient watts power low rpm generatormagnet :NdFeB
Generator case:High standard casting Aluminium alloy
| 0.5kw 200rpm | |
| Tech Data | |
| rated power(W) | 0.5kw |
| rated speed(RPM) | 200 |
| start up torque(<N*M) | 1.2 |
| rated torque(N*M) | 23.9 |
| rated voltage(V) | DC28 |
| rated current(A) | 17.86 |
| insulation class | F |
| efficency | >75% |
| PMG collocation | Y connection,three phase three wires |
| service life | >20y |
| working temperature | -25centidegree - 40centidegree |
| speed range | 0-240rpm |
| weight | 24kg |
| Material Data | |
| shaft | 45# carbon round steel with quenching and tempering treatment |
| bearing | C&U or as your requirment |
| shell | aluminum alloy |
| winding temperature class | 130 centidegree |
| permanent magnet | rare earth NdFeB |
| magnet temperature class | 150 centidegree |
| core | high grade cold rolling silicon sheet 50WW470 |
| protection grade | IP54 |
