HM-650A Automatic Gluing Machine(Feeder)
HM-650A Automatic Gluing Machine glue the paper for rigid box, paper box, hard cover, book cover, calendar, set up box and so on.
HM-650A Automatic Gluing Machine(Feeder) features:
1. This gluing machine is a transferring type of paper upper-side gluing equipment, combined with many-year
experience on packing machinery, designed along with the needs of the clients.
2. It is an ideal equipment for medium size printing packing plants to make flow line production.
3. It adopts heat fused adhesive powder to avoid traditional white emulsion from shrinking and mildewing.
4. Adjustable gluing drum to make the glue spread out on the surface of the paper.
5. The conveyor has a draft fan and keep the paper transfer from deviation.
6. Temperature control system in glue tank can guarantee the viscosity of the glue.
7. Time controller for pre-heating and to enhance production profits.
8. Circular cleaning system makes the machine cleaned within 2 minutes. So it is very convenient.
9. Speed adjustable according to skillful degree of the production worker.
10. It is characterized by rational structure, stable performance, convenient operation, easy replacement, and low labor intensity.
HM-650A Automatic Gluing Machine(Feeder) parameters:
Model |
HM-650A |
HM-850A |
Working Width |
80-600mm |
80-800mm |
Sheet Thickness |
80-200gsm |
80-200gsm |
Production Speed |
7-40pcs/min |
7-40pcs/min |
Voltage |
AC380V |
AC380V |
Power |
7.45kW |
7.45kW |
Diemension |
6350x1650x1100mm |
6350x1850x1100mm |
Net Weight |
1100kg |
1275kg |
HM-650A Automatic Gluing Machine(Feeder)'s glue: hot glue and cold glue
HM-650A Automatic Gluing Machine(Feeder) gluing effect:
HM-650A Automatic Gluing Machine(Feeder) final outputs:
